SMR540R Bluetooth Headset Teardown Internal... - FCC ID A3LSMR540R
FCC ID A3LSMR540R
Internal Photos
Bluetooth Headset
Document preview loads when visible.
Document Details
| FCC ID | A3LSMR540R |
|---|---|
| Document ID | 8966921 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Samsung Electronics Co Ltd |
| Equipment Class | Bluetooth Headset |
| Product Code | SMR540R |
| Application ID | 80mh9TefeAiAdIAcg4FWRg== |
| Application Purpose | Original Equipment |
| Application Date | 2026-01-07 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0027908797 |
| Test Firm | SGS Korea Co., Ltd |
| Certified By | Jenni Chun General Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Submitted | 2026-01-07 |
| Available | 2026-07-07 |
| Created | 2026-01-06 |
| Modified | 2026-01-06 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 3573950 |
| File SHA-256 | e60dd353c7f92f9184ceaa4322c52cc60c079cff6c60ff1abd3fec79c57022fd |
| PDF Metadata Author | Dave_Kim |
| PDF Metadata Producer | Hancom PDF 1.3.0.546; modified using SignServer Dave_Kim |
| FCC.gov Sources | FCC.gov 8966921, FCC.gov 8966885 |
