SMT580 Portable Tablet with Bluetooth, WLAN... - FCC ID A3LSMT580
FCC ID A3LSMT580
External Photographs
Portable Tablet with Bluetooth, WLAN and ANT+
Document preview loads when visible.
Document Details
| FCC ID | A3LSMT580 |
|---|---|
| Document ID | 2990921 |
| Document Type | External Photos |
| Description | External Photographs |
| Applicant | Samsung Electronics Co Ltd |
| Equipment Class | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Product Code | SMT580 |
| Application ID | nPQg4U7v8JkPqqdb2auBPg== |
| Application Purpose | Original Equipment |
| Application Date | 2016-05-13 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0027908797 |
| Test Firm | PCTEST Engineering Laboratory, Inc. |
| Certified By | Chan Ho Youn |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 11/09/2016 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-05-13 |
| Available | 2016-11-09 |
| Created | 2017-12-05 |
| Modified | 2017-12-05 |
| Pages | 8 |
| File Type | Adobe Acrobat PDF |
| File Size | 394951 |
| File SHA-256 | 82acb483719951ad50f49b6839c8ab26c8ddbb4d8ac41b9e9fbefd8453a7a30a |
| PDF Metadata Producer | GPL Ghostscript 9.18 |
| FCC.gov Sources | FCC.gov 2990921, FCC.gov 2990943, FCC.gov 2990905, FCC.gov 2990874, FCC.gov 2990826 |
