FCC ID A3LSMT813
Portable Tablet with Bluetooth, WLAN and ANT+
by Samsung Electronics Co Ltd
Grantee Code: A3L Product Code: SMT813
Latest application date: 2016-04-06
Device Images
FCC ID Device Details
| FCC ID | A3LSMT813 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | A3L |
| Product Code | SMT813 |
| Applicant Business | Samsung Electronics Co Ltd 🇺🇸 |
| Related Domains |  samsung.com |
| Equipment Class | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Test Firm | PCTEST Engineering Laboratory, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-04-06 |
| 2402-2480 MHz | Original Equipment | 2016-04-06 |
| 2402-2480 MHz | Original Equipment | 2016-04-06 |
| 2402-2480 MHz | Original Equipment | 2016-04-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-10-03 | PDF 1.7 MB |
| Internal Photographs | Internal Photos | 2016-10-03 | PDF 828.1 KB |
| External Photographs | External Photos | 2016-10-03 | PDF 218.7 KB |
| FCC ID Label and Location | ID Label/Location Info | 2016-04-06 | PDF 73.9 KB |
| SAR Test Setup Photographs | Test Setup Photos | 2016-10-03 | PDF 414.8 KB |
| Test Setup Photographs | Test Setup Photos | 2016-10-03 | PDF 257.8 KB |
| Test Setup Photographs | Test Setup Photos | 2016-10-03 | PDF 608.8 KB |
| ANT+ Test Report | Test Report | 2016-04-06 | PDF 965.4 KB |
| Bluetooth LE Test Report | Test Report | 2016-04-06 | PDF 1.6 MB |
| Bluetooth Test Report | Test Report | 2016-04-06 | PDF 2.6 MB |
| DFS Test Report | Test Report | 2016-04-06 | PDF 931.7 KB |
| Test Report | Test Report | 2016-04-06 | PDF 634.1 KB |
| UNII Test Report 1 | Test Report | 2016-04-06 | PDF 3.7 MB |
| UNII Test Report 2 | Test Report | 2016-04-06 | PDF 4.9 MB |
| WLAN Test Report | Test Report | 2016-04-06 | PDF 4.3 MB |
| Authorization Letter | Attestation Statements | 2016-04-06 | PDF 81.1 KB |
| Label Attestation Letter | Attestation Statements | 2016-04-06 | PDF 154.4 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-04-06 | PDF 56.6 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-04-06 | PDF 56.6 KB |
| RF Exposure Info | RF Exposure Info | 2016-04-06 | PDF 1.6 MB |
| Block Diagram Metadata only | Block Diagram | PDF 676.3 KB | |
| Schematics Metadata only | Schematics | PDF 776.4 KB | |
| Antenna Separation Distance Metadata only | Operational Description | PDF 573.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 1.4 MB | |
| Operational Description Metadata only | Operational Description | PDF 828 KB | |
| Operational Description Metadata only | Operational Description | PDF 1.3 MB | |
| Sensor Triggering Document Metadata only | Operational Description | PDF 682.2 KB |
Application Information
| Application ID | tLaXxTzTOoxwZFqLgHkqwA== |
|---|---|
| Final Action Date | 2016-04-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005810205 |
| Model | SMT813 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Responsible Party | Jenni Chun, General Manager, j1.chun@samsung.com , 973-808-6375 |
| Technical Contact | Randy Ortanez, PCTEST Engineering Laboratory, Inc., tcb@pctestlab.com  , 410-290-6652 |
| Test Firm | Randy Ortanez, PCTEST Engineering Laboratory, Inc., lab@pctestlab.com , 410-290-6652 |
| TCB Email | tcb@pctestlab.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 10/03/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output is conducted. Device is a 2 x 2 MIMO configuration, enabled for 5 GHz band operations as described in this filing. This device supports 20, 40, and 80 MHz BW modes. The highest reported SAR for stand-alone and simultaneous transmission use conditions is 1.03 W/kg and 1.59 W/kg, respectively. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| tLaXxTzTOoxwZFqLgHkqwA== | 2016-04-06 | Original Equipment |
| dGuk3Pt+Q5cYgV2saQd9DA== | 2016-04-06 | Original Equipment |
| Y0JgVmDX7f0iTchpRt+btg== | 2016-04-06 | Original Equipment |
| TcH6m83uMq/CD4u+MVKVkg== | 2016-04-06 | Original Equipment |
| AxgRG88BhGFxOhVoW279zQ== | 2016-04-06 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application Y0JgVmDX7f0iTchpRt+btg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PCTEST Engineering Laboratory, LLC 7185 Oakland Mills Road Columbia, MD 21046 |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2472.0 | 0.054 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.002 |
| Output power is conducted. Device is a 2 x 2 MIMO configuration, enabled for 2.4 GHz operations as described in this filing. The highest reported SAR for stand-alone and simultaneous transmission use conditions is 0.92 W/kg and 1.59 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application Y0JgVmDX7f0iTchpRt+btg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2472.0 | 0.054 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.002 |
| Output power is conducted. Device is a 2 x 2 MIMO configuration, enabled for 2.4 GHz operations as described in this filing. The highest reported SAR for stand-alone and simultaneous transmission use conditions is 0.92 W/kg and 1.59 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PCTEST Engineering Laboratory, LLC 7185 Oakland Mills Road Columbia, MD 21046 |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.051 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.053 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.055 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.055 |
| Power output is conducted. Device is a 2 x 2 MIMO configuration, enabled for 5 GHz band operations as described in this filing. This device supports 20, 40, and 80 MHz BW modes. The highest reported SAR for stand-alone and simultaneous transmission use conditions is 1.03 W/kg and 1.59 W/kg, respectively. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application tLaXxTzTOoxwZFqLgHkqwA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.051 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.053 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.055 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.055 |
| Power output is conducted. Device is a 2 x 2 MIMO configuration, enabled for 5 GHz band operations as described in this filing. This device supports 20, 40, and 80 MHz BW modes. The highest reported SAR for stand-alone and simultaneous transmission use conditions is 1.03 W/kg and 1.59 W/kg, respectively. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PCTEST Engineering Laboratory, LLC 7185 Oakland Mills Road Columbia, MD 21046 |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.013 |
| Power output is conducted. The highest reported SAR for stand-alone and simultaneous transmission use conditions is 0.20 W/kg and 1.59 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application TcH6m83uMq/CD4u+MVKVkg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.013 |
| Power output is conducted. The highest reported SAR for stand-alone and simultaneous transmission use conditions is 0.20 W/kg and 1.59 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PCTEST Engineering Laboratory, LLC 7185 Oakland Mills Road Columbia, MD 21046 |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application dGuk3Pt+Q5cYgV2saQd9DA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PCTEST Engineering Laboratory, LLC 7185 Oakland Mills Road Columbia, MD 21046 |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Class B Computing Device/Personal Computer |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 16 CC | 15B | - |
| 16: | If the subject device requires shielded interface cables to ensure compliance, the user's manual must advise the user of this requirement. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application AxgRG88BhGFxOhVoW279zQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMT813 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Class B Computing Device/Personal Computer |
| Notes: | Portable Tablet with Bluetooth, WLAN and ANT+ |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 16 CC | 15B | - |
| 16: | If the subject device requires shielded interface cables to ensure compliance, the user's manual must advise the user of this requirement. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
