FCC ID A3LSMW708Y
WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac
by Samsung Electronics Co Ltd
Grantee Code: A3L Product Code: SMW708Y
Latest application date: 2016-03-15
Device Images
FCC ID Device Details
| FCC ID | A3LSMW708Y |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | A3L |
| Product Code | SMW708Y |
| Applicant Business | Samsung Electronics Co Ltd 🇺🇸 |
| Related Domains |  samsung.com |
| Equipment Class | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Test Firm | UL Korea, Ltd. Suwon Laboratory |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-03-15 |
| 2402-2480 MHz | Original Equipment | 2016-03-15 |
| 825.5-847.5 MHz | Original Equipment | 2016-03-15 |
| 2402-2480 MHz | Original Equipment | 2016-03-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Test Setup Photos_20160307_v1 - 16K22999-E5V1 FCC SetupPhoto WWAN | Users Manual | 2016-09-11 | PDF 284.4 KB |
| User Manual_20160307_v1 - 7. A3LSMW708Y_User manual_FCC | Users Manual | 2016-09-11 | PDF 284.4 KB |
| Internal Photos_20160307_v1 - 16K22999-FCC Internal Photo_Part1 | Internal Photos | 2016-09-11 | PDF 4.3 MB |
| Internal Photos_20160307_v1 - 16K22999-FCC Internal Photo_Part2 | Internal Photos | 2016-09-11 | PDF 3.8 MB |
| External Photos_20160307_v1 - 16K22999-FCC External Photo | External Photos | 2016-09-11 | PDF 5.3 MB |
| ID Label & Location Info._20160307_v1 - 6. A3LSMW708Y _Label Location_final | ID Label/Location Info | 2016-03-15 | PDF 205.5 KB |
| RF Exposure Info._20160307_v1 - 16K22999-S1V1 FCC Report SAR_App A_Photos & Ant. | Test Setup Photos | 2016-09-11 | PDF 1.1 MB |
| Test Setup Photos_20160307_v1 - 16K22999-E1V1_FCC SetupPhoto DTS WLAN | Test Setup Photos | 2016-09-11 | PDF 312.2 KB |
| Test Setup Photos_20160307_v1 - 16K22999-E2V1 FCC SetupPhoto BLE | Test Setup Photos | 2016-09-11 | PDF 313.5 KB |
| Test Setup Photos_20160307_v1 - 16K22999-E3V1 FCC SetupPhoto BT | Test Setup Photos | 2016-09-11 | PDF 343.7 KB |
| Test Setup Photos_20160307_v1 - 16K22999-E4V1_FCC SetupPhoto UNII DFS WLAN | Test Setup Photos | 2016-09-11 | PDF 364.7 KB |
| Test Setup Photos_20160307_v1 - 16K22999-E5V1 FCC SetupPhoto WWAN | Test Setup Photos | 2016-09-11 | PDF 381 KB |
| Test Setup Photos_20160307_v1 - LBE20160683_SM-W708Y_Appendix_FCC _Cer._ | Test Setup Photos | 2016-09-11 | PDF 1.1 MB |
| Test Report_20160307_v1 - 15K21999-E1V3_FCC Report DTS WLAN _Part1 | Test Report | 2016-03-15 | PDF 5.1 MB |
| Test Report_20160307_v1 - 15K21999-E1V3_FCC Report DTS WLAN _Part2 | Test Report | 2016-03-15 | PDF 5.4 MB |
| Test Report_20160307_v1 - 15K21999-E1V3_FCC Report DTS WLAN _Part3 | Test Report | 2016-03-15 | PDF 3.1 MB |
| Test Report_20160307_v1 - 15K21999-E2V1 FCC Report BLE | Test Report | 2016-03-15 | PDF 2.1 MB |
| Test Report_20160307_v1 - 15K21999-E3V1 FCC Report BT_Part1 | Test Report | 2016-03-15 | PDF 3.9 MB |
| Test Report_20160307_v1 - 15K21999-E3V1 FCC Report BT_Part2 | Test Report | 2016-03-15 | PDF 2.1 MB |
| Test Report_20160307_v1 - 15K21999-E4V2_FCC Report UNII DFS WLAN_Part1 | Test Report | 2016-03-15 | PDF 5.3 MB |
| Test Report_20160307_v1 - 15K21999-E4V2_FCC Report UNII DFS WLAN_Part2 | Test Report | 2016-03-15 | PDF 5.5 MB |
| Test Report_20160307_v1 - 15K21999-E4V2_FCC Report UNII DFS WLAN_Part3 | Test Report | 2016-03-15 | PDF 5.3 MB |
| Test Report_20160307_v1 - 15K21999-E4V2_FCC Report UNII DFS WLAN_Part4 | Test Report | 2016-03-15 | PDF 5.2 MB |
| Test Report_20160307_v1 - 15K21999-E4V2_FCC Report UNII DFS WLAN_Part5 | Test Report | 2016-03-15 | PDF 5.4 MB |
| Test Report_20160307_v1 - 15K21999-E4V2_FCC Report UNII DFS WLAN_Part6 | Test Report | 2016-03-15 | PDF 4.2 MB |
| Test Report_20160307_v1 - 16K22598-E1V2_FCC Report DTS WLAN | Test Report | 2016-03-15 | PDF 248.4 KB |
| Test Report_20160307_v1 - 16K22598-E2V1 FCC Report BLE | Test Report | 2016-03-15 | PDF 202.6 KB |
| Test Report_20160307_v1 - 16K22598-E3V1 FCC Report BT | Test Report | 2016-03-15 | PDF 247.5 KB |
| Test Report_20160307_v1 - 16K22598-E4V3_FCC Report UNII DFS WLAN | Test Report | 2016-03-15 | PDF 417 KB |
| Test Report_20160307_v1 - 16K22598-E5V2 FCC Report WWAN_Part1 | Test Report | 2016-03-15 | PDF 5.4 MB |
| Test Report_20160307_v1 - 16K22598-E5V2 FCC Report WWAN_Part2 | Test Report | 2016-03-15 | PDF 5.3 MB |
| Test Report_20160307_v1 - 16K22598-E5V2 FCC Report WWAN_Part3 | Test Report | 2016-03-15 | PDF 4.9 MB |
| Test Report_20160307_v1 - 16K22999-E1V1_FCC Report DTS WLAN | Test Report | 2016-03-15 | PDF 244.9 KB |
| Test Report_20160307_v1 - 16K22999-E2V1 FCC Report BLE | Test Report | 2016-03-15 | PDF 202.2 KB |
| Test Report_20160307_v1 - 16K22999-E3V1 FCC Report BT | Test Report | 2016-03-15 | PDF 246.6 KB |
| Test Report_20160307_v1 - 16K22999-E4V1_FCC Report UNII DFS WLAN | Test Report | 2016-03-15 | PDF 328.4 KB |
| Test Report_20160307_v1 - 16K22999-E5V1 FCC Report WWAN | Test Report | 2016-03-15 | PDF 403.7 KB |
| Test Report_20160307_v1 - LBE20160683_SM-W708Y_Test Report_FCC _Cer._ | Test Report | 2016-03-15 | PDF 1.8 MB |
| Cover Letters_20160307_v1 - [A3LSMW708Y] Agent Authorization Letter | Cover Letter(s) | 2016-03-15 | PDF 78.4 KB |
| Cover Letters_20160307_v1 - [A3LSMW708Y] Request for confidentiality letter_ | Cover Letter(s) | 2016-03-15 | PDF 294 KB |
| RF Exposure Info._20160307_v1 - 16K22999-S1V1 FCC Report SAR | RF Exposure Info | 2016-03-15 | PDF 1.3 MB |
| RF Exposure Info._20160307_v1 - 16K22999-S1V1 FCC Report SAR_App B_Highest SAR T | RF Exposure Info | 2016-03-15 | PDF 303.7 KB |
| RF Exposure Info._20160307_v1 - 16K22999-S1V1 FCC Report SAR_App C_System Check | RF Exposure Info | 2016-03-15 | PDF 343.3 KB |
| RF Exposure Info._20160307_v1 - 16K22999-S1V1 FCC Report SAR_App D_SAR Tissue In | RF Exposure Info | 2016-03-15 | PDF 1.3 MB |
| RF Exposure Info._20160307_v1 - 16K22999-S1V1 FCC Report SAR_App E_Probe Cal. Ce | RF Exposure Info | 2016-03-15 | PDF 4 MB |
| RF Exposure Info._20160307_v1 - 16K22999-S1V1 FCC Report SAR_App F_Dipole Cal. C | RF Exposure Info | 2016-03-15 | PDF 5.8 MB |
| Block Diagrams_20160307_v1 - 5. SM-W708Y_Block Diagram FCC Metadata only | Block Diagram | PDF 377.8 KB | |
| Schematics_20160307_v1 - 9. SM-W708Y_REV0.4_MBOM_schematics_160223F_ Metadata only | Schematics | PDF 1.4 MB | |
| Operational Description_20160307_v1 - 10. Operational description Metadata only | Operational Description | PDF 2.7 MB | |
| Operational Description_20160307_v1 - 11-1. [A3LSMW708Y] WLAN Channel Plan and T Metadata only | Operational Description | PDF 545.2 KB | |
| Operational Description_20160307_v1 - 11. WIFI_Operational description Metadata only | Operational Description | PDF 969.4 KB | |
| Operational Description_20160307_v1 - 12. BT_Operational description Metadata only | Operational Description | PDF 720.7 KB | |
| Operational Description_20160307_v1 - 18. A3LSMW708Y LTE Check List Metadata only | Operational Description | PDF 20.4 KB | |
| Operational Description_20160307_v1 - 20. [A3LSMW708Y] U-NII Device SW Security Metadata only | Operational Description | PDF 1.2 MB | |
| Operational Description_20160307_v1 - 21. SM-W708Y Sensor triggering distance Metadata only | Operational Description | PDF 936.8 KB | |
| Operational Description_20160307_v1 - 3. A3LSMW708Y Main ANT Specification(Gain Metadata only | Operational Description | PDF 172.2 KB | |
| Operational Description_20160307_v1 - 4-1. SM-W700_WIFI 1_antenna specification_ Metadata only | Operational Description | PDF 3.3 MB | |
| Operational Description_20160307_v1 - 4-2. SM-W700_WIFI 1_antenna specification_ Metadata only | Operational Description | PDF 3.1 MB | |
| Operational Description_20160307_v1 - 4. WM-W708Y LTE Release 10 Checklist Metadata only | Operational Description | PDF 98.9 KB | |
| Operational Description_20160307_v1 - SM-W708Y_ Product_Equality_Decl_FCC_160215 Metadata only | Operational Description | PDF 301.7 KB | |
| Parts List & Tune Up Info._20160307_v1 - 1.A3LSMW708Y_Tune-up procedure Metadata only | Parts List/Tune Up Info | PDF 54.6 KB | |
| Parts List & Tune Up Info._20160307_v1 - 2.A3LSMW708Y _Part15 Tune-up Metadata only | Parts List/Tune Up Info | PDF 207.9 KB | |
| Parts List & Tune Up Info._20160307_v1 - 8. Part List Metadata only | Parts List/Tune Up Info | PDF 202.8 KB |
Application Information
| Application ID | vj2WIakoNI9UoKRkiO4tvg== |
|---|---|
| Final Action Date | 2016-03-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005810205 |
| Model | SMW708Y |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Responsible Party | Jenni Chun, General Manager, j1.chun@samsung.com , 973-808-6375 |
| Test Firm | CY Choi, UL Korea, Ltd. Suwon Laboratory, CY.Choi@ul.com  , 82313379910 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 09/11/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. This device supports bandwidth of 20 MHz, 40 MHz and 80 MHz and 2x2 MIMO mode. The highest reported SAR values for stand-alone and simultaneous transmission exposure conditions are 0.42 W/Kg and 1.45 W/Kg respectively. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| vj2WIakoNI9UoKRkiO4tvg== | 2016-03-15 | Original Equipment |
| cUqgvvj04K8uTaSdZAHC4g== | 2016-03-15 | Original Equipment |
| axD+iRMjyi7locgJByWkUA== | 2016-03-15 | Original Equipment |
| YOSnA4MIbySFcOYLXCrW1Q== | 2016-03-15 | Original Equipment |
| +xjGfF/tCJ0cSFzYSWmLTw== | 2016-03-15 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 825.5-847.5 MHz | 0.128 | 2.5ppm | 2M69G7W | 22H | |
| 825.5-847.5 MHz | 0.106 | 2.5ppm | 2M69D7W | 22H | |
| 826.4-846.6 MHz | 0.132 | 2.5ppm | 4M08F9W | 22H | |
| 829-844 MHz | 0.123 | 2.5ppm | 8M98G7W | 22H | |
| 829-844 MHz | 0.096 | 2.5ppm | 8M98D7W | 22H | |
| 1852.4-1907.6 MHz | 0.059 | 2.5ppm | 4M07F9W | 24E | |
| 2402-2480 MHz | 0.0017 | 15C | CC | ||
| 2402-2480 MHz | 0.0091000 | 15C | CC | ||
| 2412-2472 MHz | 0.0532 | 15C | CC, MO | ||
| 5180-5240 MHz | 0.0417 | 15E | 38, CC, MO | ||
| 5260-5320 MHz | 0.0425 | 15E | 38, CC, MO | ||
| 5500-5720 MHz | 0.0404 | 15E | 38, CC, MO | ||
| 5745-5825 MHz | 0.0393 | 15E | 38, CC, MO |
Grants
TCB Grant - Application YOSnA4MIbySFcOYLXCrW1Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.132 | 2.5 PM | 4M08F9W | |
| 24E | 1852.4 - 1907.6 | 0.059 | 2.5 PM | 4M07F9W | |
| 22H | 829.0 - 844.0 | 0.123 | 2.5 PM | 8M98G7W | |
| 22H | 829.0 - 844.0 | 0.096 | 2.5 PM | 8M98D7W | |
| 22H | 825.5 - 847.5 | 0.128 | 2.5 PM | 2M69G7W | |
| 22H | 825.5 - 847.5 | 0.106 | 2.5 PM | 2M69D7W |
| Power output listed is ERP for bands below 1 GHz and EIRP for bands above 1 GHz. Values listed for LTE operations are for highest power and widest bandwidth for each LTE band and modulation. This device supports LTE bandwidths of: 1.4MHz, 3MHz, 5MHz and 10MHz under Part 22H (LTE Band 5 824-849MHz). LTE support for Rel. 10 is limited to downlink features only and does not support uplink carrier aggregation or other advanced features. This device contains functions that are not operational in U.S. and its territories. Filings under this FCC ID are approved only for U.S. operations. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for body-worn accessory and simultaneous transmission use conditions are 1.02 W/kg and 1.45 W/kg, respectively. |
EAS Grant - Application YOSnA4MIbySFcOYLXCrW1Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.132 | 2.5 PM | 4M08F9W | |
| 24E | 1852.4 - 1907.6 | 0.059 | 2.5 PM | 4M07F9W | |
| 22H | 829.0 - 844.0 | 0.123 | 2.5 PM | 8M98G7W | |
| 22H | 829.0 - 844.0 | 0.096 | 2.5 PM | 8M98D7W | |
| 22H | 825.5 - 847.5 | 0.128 | 2.5 PM | 2M69G7W | |
| 22H | 825.5 - 847.5 | 0.106 | 2.5 PM | 2M69D7W |
| Power output listed is ERP for bands below 1 GHz and EIRP for bands above 1 GHz. Values listed for LTE operations are for highest power and widest bandwidth for each LTE band and modulation. This device supports LTE bandwidths of: 1.4MHz, 3MHz, 5MHz and 10MHz under Part 22H (LTE Band 5 824-849MHz). LTE support for Rel. 10 is limited to downlink features only and does not support uplink carrier aggregation or other advanced features. This device contains functions that are not operational in U.S. and its territories. Filings under this FCC ID are approved only for U.S. operations. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for body-worn accessory and simultaneous transmission use conditions are 1.02 W/kg and 1.45 W/kg, respectively. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.0417 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.0425 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.0404 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.0393 |
| Output power listed is conducted. This device supports bandwidth of 20 MHz, 40 MHz and 80 MHz and 2x2 MIMO mode. The highest reported SAR values for stand-alone and simultaneous transmission exposure conditions are 0.42 W/Kg and 1.45 W/Kg respectively. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application vj2WIakoNI9UoKRkiO4tvg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.0417 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.0425 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.0404 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.0393 |
| Output power listed is conducted. This device supports bandwidth of 20 MHz, 40 MHz and 80 MHz and 2x2 MIMO mode. The highest reported SAR values for stand-alone and simultaneous transmission exposure conditions are 0.42 W/Kg and 1.45 W/Kg respectively. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0091 |
| Power Output listed is Conducted. The highest reported SAR values for stand-alone and simultaneous transmission exposure conditions are 0.21 W/Kg and 1.24 W/Kg respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application cUqgvvj04K8uTaSdZAHC4g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0091 |
| Power Output listed is Conducted. The highest reported SAR values for stand-alone and simultaneous transmission exposure conditions are 0.21 W/Kg and 1.24 W/Kg respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15B | - |
EAS Grant - Application axD+iRMjyi7locgJByWkUA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15B | - |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0017 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.0532 |
| Output power listed is maximum conducted. This device supports WLAN bandwidth of 20 MHz and 2x2 MIMO mode. The highest reported SAR values for stand-alone and simultaneous transmission exposure conditions are 1.03 W/Kg and 1.41 W/Kg respectively |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application +xjGfF/tCJ0cSFzYSWmLTw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 03/15/2016 Application Dated: 03/11/2016 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LSMW708Y |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | WCDMA/LTE Tablet + BT/BLE and DTS/UNII a/b/g/n/ac |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0017 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.0532 |
| Output power listed is maximum conducted. This device supports WLAN bandwidth of 20 MHz and 2x2 MIMO mode. The highest reported SAR values for stand-alone and simultaneous transmission exposure conditions are 1.03 W/Kg and 1.41 W/Kg respectively |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
