FCC ID A3LSMZ200F
LTE Phone with Bluetooth and WLAN
by Samsung Electronics Co Ltd
Grantee Code: A3L Product Code: SMZ200F
Latest application date: 2016-07-18
Device Images
FCC ID Device Details
| FCC ID | A3LSMZ200F |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | A3L |
| Product Code | SMZ200F |
| Applicant Business | Samsung Electronics Co Ltd 🇺🇸 |
| Related Domains |  samsung.com |
| Equipment Class | LTE Phone with Bluetooth and WLAN |
| Test Firm | HCT Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 824.7-848.3 MHz | Original Equipment | 2016-07-18 |
| 2402-2480 MHz | Original Equipment | 2016-07-18 |
| 2402-2480 MHz | Original Equipment | 2016-07-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2017-01-14 | PDF 4.2 MB |
| Internal Photographs | Internal Photos | 2017-01-14 | PDF 1,008.6 KB |
| External Photographs | External Photos | 2017-01-14 | PDF 490.4 KB |
| FCC ID Label and Location | ID Label/Location Info | 2016-07-18 | PDF 39.6 KB |
| SAR Test Setup Photographs | Test Setup Photos | 2017-01-14 | PDF 417.2 KB |
| Test Setup Photographs | Test Setup Photos | 2017-01-14 | PDF 340.3 KB |
| Test Setup Photographs | Test Setup Photos | 2017-01-14 | PDF 525.9 KB |
| Test Setup Photographs | Test Setup Photos | 2017-01-14 | PDF 1.2 MB |
| Bluetooth LE Test Report | Test Report | 2016-07-18 | PDF 2.4 MB |
| Test Report | Test Report | 2016-07-18 | PDF 531.2 KB |
| Test Report | Test Report | 2016-07-18 | PDF 2.6 MB |
| Test Report | Test Report | 2016-07-18 | PDF 4.1 MB |
| WLAN Test Report | Test Report | 2016-07-18 | PDF 2.4 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-07-18 | PDF 197.3 KB |
| RF Exposure Info | RF Exposure Info | 2016-07-18 | PDF 3.8 MB |
| Block Diagram Metadata only | Block Diagram | PDF 354.3 KB | |
| Schematics 1 Metadata only | Schematics | PDF 4.1 MB | |
| Schematics 2 Metadata only | Schematics | PDF 2.2 MB | |
| Antenna Separation Distance Metadata only | Operational Description | PDF 137.1 KB | |
| Antenna Specs Metadata only | Operational Description | PDF 728.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 685.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 1.8 MB | |
| Parts List and Tune-Up Procedure Metadata only | Parts List/Tune Up Info | PDF 302.4 KB |
Application Information
| Application ID | iLUwr9ShZzro76wgDm7NlQ== |
|---|---|
| Final Action Date | 2016-07-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0027908797 |
| Model | SMZ200F |
| Frequency Range | 824.7-848.3 MHz |
| Equipment Class | TNE - Licensed Non-Broadcast Transmitter Held to Ear |
| Device Description | LTE Phone with Bluetooth and WLAN |
| Responsible Party | Jenni Chun, General Manager, j1.chun@samsung.com , 973-808-6375 |
| Technical Contact | Randy Ortanez, PCTEST Engineering Laboratory, Inc., tcb@pctestlab.com  , 410-290-6652 |
| Test Firm | Lee Yoon-Jung, HCT Co., Ltd., yjlee@hct.co.kr  , 82-31-645-6432 |
| TCB Email | tcb@pctestlab.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 01/14/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is ERP. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm separation between the device and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission use conditions is 0.45 W/kg, 0.47 W/kg, 0.59 W/kg, and 1.03 W/kg, respectively. This device also contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| iLUwr9ShZzro76wgDm7NlQ== | 2016-07-18 | Original Equipment |
| XYko4c+Fo9T+6B/L+tCuPw== | 2016-07-18 | Original Equipment |
| VnPD8ewMeXASwYDFgk6spw== | 2016-07-18 | Original Equipment |
| MCdC65WSgCtaE61xkfIqJQ== | 2016-07-18 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 15B | 16, CC | ||||
| 824.7-848.3 MHz | 0.064 | 2.5ppm | 1M10G7D | 22H | |
| 824.7-848.3 MHz | 0.046 | 2.5ppm | 1M10W7D | 22H | |
| 825.5-847.5 MHz | 0.066 | 2.5ppm | 2M68G7D | 22H | |
| 825.5-847.5 MHz | 0.05 | 2.5ppm | 2M69W7D | 22H | |
| 826.5-846.5 MHz | 0.065 | 2.5ppm | 4M50G7D | 22H | |
| 826.5-846.5 MHz | 0.05 | 2.5ppm | 4M50W7D | 22H | |
| 829-844 MHz | 0.062 | 2.5ppm | 8M97G7D | 22H | |
| 829-844 MHz | 0.047 | 2.5ppm | 8M97W7D | 22H | |
| 2402-2480 MHz | 0.0140000 | 15C | CC | ||
| 2402-2480 MHz | 0.001 | 15C | CC | ||
| 2412-2462 MHz | 0.05 | 15C | CC |
