SPHM500 Dual-Band CDMA Phone with Bluetooth... - FCC ID A3LSPHM500

FCC ID A3LSPHM500

SAR Test Setup Photos

Dual-Band CDMA Phone with Bluetooth

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSPHM500
Document ID673365
Document TypeTest Setup Photos
DescriptionSAR Test Setup Photos
Document TitleTemplate SAR photo
ApplicantSamsung Electronics Co Ltd
Equipment ClassDual-Band CDMA Phone with Bluetooth
Product CodeSPHM500
Application IDjufxpkUcxjnCGyNjH21t5g==
Application PurposeOriginal Equipment
Application Date2006-06-26
Frequency Range1851.25-1908.75 MHz
FRN0027908797
Test FirmPCTEST Engineering Laboratory, Inc.
Certified ByRandy Ortanez President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/23/2006
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartYes
Submitted2006-06-26
Available2006-12-23
Created2006-06-20
Modified2006-06-20
Pages15
File TypeAdobe Acrobat PDF
File Size1532427
File SHA-25695eb9ce77ba2a0d1c88d514e12b8e451d2e3324c5a383249aaea9f4625efeb3f
PDF Metadata Authorcourtenay
PDF Metadata ProducerTemplate SAR photo - Microsoft Word Acrobat PDFWriter 5.0 for Windows NT
FCC.gov SourcesFCC.gov 673365
