FCC ID A3LWSZWM110C00
Z-wave Module
by Samsung Electronics Co Ltd
Grantee Code: A3L Product Code: WSZWM110C00
Latest application date: 2015-11-06
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 908.4-916 MHz | Original Equipment | 2015-11-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-11-06 | PDF 210 KB |
| Internal Photos | Internal Photos | 2015-11-06 | PDF 62.1 KB |
| External Photos | External Photos | 2015-11-06 | PDF 111.5 KB |
| Label & Location | ID Label/Location Info | 2015-11-06 | PDF 162 KB |
| Test Setup Photos | Test Setup Photos | 2015-11-06 | PDF 351.9 KB |
| Test Report | Test Report | 2015-11-06 | PDF 828.7 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2015-11-06 | PDF 36.3 KB |
| Modular Approval Letter | Cover Letter(s) | 2015-11-06 | PDF 42.7 KB |
| Product Certification Representative Auth Letter | Cover Letter(s) | 2015-11-06 | PDF 36 KB |
| Block Diagram Metadata only | Block Diagram | PDF 32.4 KB | |
| Schematics Metadata only | Schematics | PDF 65.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 17 KB |
Application Information
| Application ID | C8EFeLDTmPmRPDyFCcai/Q== |
|---|---|
| Final Action Date | 2015-11-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005810205 |
| Model | WSZWM110C00 |
| Frequency Range | 908.4-916 MHz |
| Equipment Class | DXT - Part 15 Low Power Transceiver, Rx Verified |
| Device Description | Z-wave Module |
| Responsible Party | Jenni Chun, General Manager, j1.chun@samsung.com  , 973-808-6375 |
| Test Firm | Sung-Su Lim, KCTL INC, sungsu.lim@kctl.co.kr  , +82-31-326-6713 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| C8EFeLDTmPmRPDyFCcai/Q== | 2015-11-06 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 908.4-916 MHz | 15C |
Grants
TCB Grant - Application C8EFeLDTmPmRPDyFCcai/Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 11/06/2015 Application Dated: 11/06/2015 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LWSZWM110C00 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Low Power Transceiver, Rx Verified |
| Notes: | Z-wave Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 908.4 - 916.0 |
| Single Modular Approval. |
EAS Grant - Application C8EFeLDTmPmRPDyFCcai/Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 11/06/2015 Application Dated: 11/06/2015 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LWSZWM110C00 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Low Power Transceiver, Rx Verified |
| Notes: | Z-wave Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 908.4 - 916.0 |
| Single Modular Approval. |
