FCC ID A4R-CAP1
Smart BLE Device
by Google LLC
Grantee Code: A4R Product Code: CAP1
Latest application date: 2015-04-24
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-04-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-10-18 | PDF 120.4 KB |
| Photos Internal | Internal Photos | 2015-10-18 | PDF 236.4 KB |
| Photos External | External Photos | 2015-10-18 | PDF 1.3 MB |
| Label | ID Label/Location Info | 2015-04-24 | PDF 27.1 KB |
| Photos Test Setup | Test Setup Photos | 2015-10-18 | PDF 84.6 KB |
| Test Report BLE | Test Report | 2015-04-24 | PDF 1.1 MB |
| Agent Letter | Cover Letter(s) | 2015-04-24 | PDF 178.8 KB |
| Confidentiality Letter | Cover Letter(s) | 2015-04-24 | PDF 693.9 KB |
| RF Exposure | RF Exposure Info | 2015-04-24 | PDF 417.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 88 KB | |
| Schematics Metadata only | Schematics | PDF 428.2 KB | |
| Antenna Spec Metadata only | Operational Description | PDF 199.6 KB | |
| Operation Description Metadata only | Operational Description | PDF 77.4 KB |
Application Information
| Application ID | b7lrL7xBO5tNIr0RCjo/Wg== |
|---|---|
| Final Action Date | 2015-04-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0020499539 |
| Model | CAP1 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Smart BLE Device |
| Responsible Party | Angie Du, angiedu@google.com  , 650-799-1437 |
| Technical Contact | Grace Rincand, UL VERIFICATION SERVICES INC., Grace.Rincand@ul.com  , (510) 771-1000 |
| Non-Technical Contact | Grace Rincand, UL Verification Services Inc., Grace.Rincand@ul.com , 510-771-1000 |
| Test Firm | Jay Kogoma, UL Verification Services Inc. (formerly UL CCS), jay.kogoma@ul.com , 510-319-4135 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 10/18/2015 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| b7lrL7xBO5tNIr0RCjo/Wg== | 2015-04-24 | Original Equipment |
Grants
TCB Grant - Application b7lrL7xBO5tNIr0RCjo/Wg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 04/24/2015 Application Dated: 04/21/2015 |
| Google LLC |
| 1600 Amphitheatre Parkway |
| Mountain View, CA 94043 |
| Attention: Angie Du |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A4R-CAP1 |
| Name of Grantee: | Google LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | Smart BLE Device |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.002 |
| Output power listed is conducted. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application b7lrL7xBO5tNIr0RCjo/Wg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Google LLC 1600 Amphitheatre Parkway Mountain View, CA 94043 United States |
Date of Grant: 04/24/2015 Application Dated: 04/21/2015 |
| Attention: Angie Du |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A4R-CAP1 |
| Name of Grantee: | Google LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | Smart BLE Device |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.002 |
| Output power listed is conducted. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
