FCC ID A4RRUX-J42
Multimedia Streaming Device with BLE, 2.4Ghz and 5GHz WLAN Radios
by Google LLC
Grantee Code: A4R Product Code: RUXJ42
Latest application date: 2015-09-22
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2015-09-22 |
| 2402-2480 MHz | Original Equipment | 2015-09-22 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| RUX-J42_Manualdraft.pdf | Users Manual | 2016-03-20 | PDF 153.3 KB |
| InternalPhotos-A4RRUX-J42.pdf | Internal Photos | 2016-03-20 | PDF 939.3 KB |
| ExternalPhotos-A4RRUX-J42.pdf | External Photos | 2016-03-20 | PDF 444.8 KB |
| Label location A4RRUX-J42.pdf | ID Label/Location Info | 2015-09-22 | PDF 51.2 KB |
| 15U20918-E1 FCC IC DTS WLAN Report Final 7-22-15_Photos Only.pdf | Test Setup Photos | 2016-03-20 | PDF 629.5 KB |
| 15U20918-E2 UNII WLAN Final 8-3-15_Photos Only.pdf | Test Setup Photos | 2016-03-20 | PDF 819 KB |
| 15U20918-E4 FCC_IC BLE Final 7-22-15_Photos Only.pdf | Test Setup Photos | 2016-03-20 | PDF 629.1 KB |
| 15U20918-E1 FCC IC DTS WLAN Report Final 7-22-15_NO photos_Part1.pdf | Test Report | 2015-09-22 | PDF 2.9 MB |
| 15U20918-E1 FCC IC DTS WLAN Report Final 7-22-15_NO photos_Part2.pdf | Test Report | 2015-09-22 | PDF 3.5 MB |
| 15U20918-E10 FCC IC RF EXPOSURE REPORT Final 7-29-15.pdf Metadata only | Test Report | 2015-09-22 | PDF 293.3 KB |
| 15U20918-E2 FCC UNII WLAN Final 8-3-15_No Photos_Part1.pdf | Test Report | 2015-09-22 | PDF 5.1 MB |
| 15U20918-E2 FCC UNII WLAN Final 8-3-15_No Photos_Part2.pdf | Test Report | 2015-09-22 | PDF 5.5 MB |
| 15U20918-E4 FCC_IC BLE Final 7-22-15_No Photos.pdf | Test Report | 2015-09-22 | PDF 3 MB |
| FCC Request for Confidentiality RUX-J42.pdf | Cover Letter(s) | 2015-09-22 | PDF 238.9 KB |
| v3 FCC agent auth letter_A4RRUX-J42_07_24_15.pdf | Cover Letter(s) | 2015-09-22 | PDF 202.1 KB |
| 15U20918-E10 FCC IC RF EXPOSURE REPORT Final 7-29-15.pdf | RF Exposure Info | 2015-09-22 | PDF 293.3 KB |
| RUX-J42 BlockDiagram_Jul22.pdf Metadata only | Block Diagram | PDF 483.2 KB | |
| RUX-J42 Schematics_Jul22.pdf Metadata only | Schematics | PDF 649.9 KB | |
| RUX-J42-TheoryofOperation.pdf Metadata only | Operational Description | PDF 99.2 KB | |
| SoftwareOperationalDescription_RUX-J42_Jul_29_2015.pdf Metadata only | Operational Description | PDF 262.2 KB |
Application Information
| Application ID | UUfcBGTvC96I6c74zhpKmg== |
|---|---|
| Final Action Date | 2015-09-22 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0020499539 |
| Model | RUX-J42 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Multimedia Streaming Device with BLE, 2.4Ghz and 5GHz WLAN Radios |
| Responsible Party | Angie Du, angiedu@google.com  , 650-799-1437 |
| Technical Contact | Grace Rincand, UL VERIFICATION SERVICES INC., Grace.Rincand@ul.com  , 510.771.1087 |
| Non-Technical Contact | Grace Rincand, UL VERIFICATION SERVICES INC., Grace.Rincand@ul.com , 510-771-1000 |
| Test Firm | Jay Kogoma, UL Verification Services Inc. (formerly UL CCS), jay.kogoma@ul.com , 510-319-4135 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 03/20/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is maximum conducted. This device supports WLAN bandwidths of 20 MHz, 40 MHz and 80 MHz.This transmitter is approved for use in mobile RF exposure category configurations with the antenna(s) installed to provide a separation distance of at least 20 cm from all persons. Users must be provided with installation and operating instructions for complying with FCC RF exposure requirements. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| UUfcBGTvC96I6c74zhpKmg== | 2015-09-22 | Original Equipment |
| IZ1qiycr05YtmwtPEUnGpA== | 2015-09-22 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules | Grant Notes |
|---|---|---|---|
| 2402-2480 MHz | 0.005 | 15C | CC |
| 2402-2480 MHz | 0.004 | 15C | CC |
| 2412-2462 MHz | 0.05 | 15C | CC |
| 5190-5230 MHz | 0.021 | 15E | 38, CC |
| 5210 MHz | 0.005 | 15E | 38, CC |
| 5260-5320 MHz | 0.031 | 15E | 38, CC |
| 5270-5310 MHz | 0.018 | 15E | 38, CC |
| 5290 MHz | 0.006 | 15E | 38, CC |
| 5500-5700 MHz | 0.036 | 15E | 38, CC |
| 5500-5700 MHz | 0.035 | 15E | 38, CC |
| 5510-5670 MHz | 0.026 | 15E | 38, CC |
| 5530-5690 MHz | 0.008 | 15E | 38, CC |
| 5690 MHz | 0.006 | 15E | 38, CC |
| 5710 MHz | 0.018 | 15E | 38, CC |
| 5720 MHz | 0.022 | 15E | 38, CC |
| 5720 MHz | 0.023 | 15E | 38, CC |
| 5745-5825 MHz | 0.026 | 15E | 38, CC |
| 5755-5795 MHz | 0.016 | 15E | 38, CC |
| 5755 MHz | 0.003 | 15E | 38, CC |
Grants
TCB Grant - Application UUfcBGTvC96I6c74zhpKmg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 09/22/2015 Application Dated: 09/21/2015 |
| Google LLC |
| 1600 Amphitheatre Parkway |
| Mountain View, CA 94043 |
| Attention: Angie Du |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A4RRUX-J42 |
| Name of Grantee: | Google LLC |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Multimedia Streaming Device with BLE, 2.4Ghz and 5GHz WLAN Radios |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.03 | ||
| 38 CC | 15E | 5190.0 - 5230.0 | 0.021 | ||
| 38 CC | 15E | 5210.0 - 5210.0 | 0.005 | ||
| 38 CC | 15E | 5260.0 - 5320.0 | 0.031 | ||
| 38 CC | 15E | 5270.0 - 5310.0 | 0.018 | ||
| 38 CC | 15E | 5290.0 - 5290.0 | 0.006 | ||
| 38 CC | 15E | 5500.0 - 5700.0 | 0.035 | ||
| 38 CC | 15E | 5720.0 - 5720.0 | 0.023 | ||
| 38 CC | 15E | 5510.0 - 5670.0 | 0.026 | ||
| 38 CC | 15E | 5710.0 - 5710.0 | 0.018 | ||
| 38 CC | 15E | 5530.0 - 5690.0 | 0.008 | ||
| 38 CC | 15E | 5690.0 - 5690.0 | 0.006 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.026 | ||
| 38 CC | 15E | 5755.0 - 5795.0 | 0.016 | ||
| 38 CC | 15E | 5755.0 - 5755.0 | 0.003 | ||
| 38 CC | 15E | 5500.0 - 5700.0 | 0.036 | ||
| 38 CC | 15E | 5720.0 - 5720.0 | 0.022 |
| Output power listed is maximum conducted. This device supports WLAN bandwidths of 20 MHz, 40 MHz and 80 MHz.This transmitter is approved for use in mobile RF exposure category configurations with the antenna(s) installed to provide a separation distance of at least 20 cm from all persons. Users must be provided with installation and operating instructions for complying with FCC RF exposure requirements. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
