XAM29 XOUNDBAR Teardown Internal Photos - FCC ID A4V-XAM29

FCC ID A4V-XAM29

Internal Photos

XOUNDBAR

by Xmi Pte Ltd

Document preview loads when visible.

Document Details

FCC IDA4V-XAM29
Document ID3455415
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantXmi Pte Ltd
Equipment ClassXOUNDBAR
Product CodeXAM29
Application ID1WdjWbOC5uhrADKkN3MP3Q==
Application PurposeOriginal Equipment
Application Date2017-07-07
Frequency Range2402-2480 MHz
FRN0021333745
Test FirmShenzhen Alpha Product Testing Co., Ltd.
Certified ByChoon Hong Soo Senior Manager Product Development
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-07-07
Available2017-07-07
Created2017-06-14
Modified2017-06-14
Pages3
File TypeAdobe Acrobat PDF
File Size521118
File SHA-25667c6293412b04eddbaa99da367aee033190597cf1ad3ddec9ef87aefa2e844cf
PDF Metadata Author亢国超
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3455415
