RG97 Wireless Receiver Test Setup Photos - FCC ID A5MRG97

FCC ID A5MRG97

Test Setup Photos

Wireless Receiver

by Lenovo (Beijing) Limited

Document preview loads when visible.

Document Details

FCC IDA5MRG97
Document ID5876099
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleCN22XA1J 001_FCC 15C_Appendix A
ApplicantLenovo (Beijing) Limited
Equipment ClassWireless Receiver
Product CodeRG97
Application IDizGrQZ0EdDjVbPJ3DKw3GQ==
Application PurposeOriginal Equipment
Application Date2022-05-13
Frequency Range2402-2480 MHz
FRN0021340799
Test FirmTUV Rheinland (Shenzhen) Co., Ltd.
Certified ByYang Liu Compliance Engineer
Short-Term ConfidentialityYes
Long-Term ConfidentialityNo
Short-Term Confidentiality Date11/09/2022
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2022-05-13
Available2022-11-09
Created2022-05-12
Modified2022-05-12
Pages3
File TypeAdobe Acrobat PDF
File Size248564
File SHA-256845a1f7530f82593f86b42f8b7c56fdca7914aa4a39c82e4a891b8bd990807b4
PDF Metadata AuthorLinlin
PDF Metadata ProducerGPL Ghostscript 9.05 Linlin
FCC.gov SourcesFCC.gov 5876099
