24ZBPA100 Radio Module External Photos - FCC ID A7D-24ZB-PA100

FCC ID A7D-24ZB-PA100

External Photos

Radio Module

by Talon Communications, Inc.

Document preview loads when visible.

Document Details

FCC IDA7D-24ZB-PA100
Document ID2868426
Document TypeExternal Photos
DescriptionExternal Photos
ApplicantTalon Communications, Inc.
Equipment ClassRadio Module
Product Code24ZBPA100
Application IDwrE/M6CgUY69E1Nyc4Z8iQ==
Application PurposeOriginal Equipment
Application Date2016-01-11
Frequency Range2405-2475 MHz
FRN0021358643
Test FirmIntertek Testing Services Shenzhen Ltd.
Certified ByStella Yang Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2016-01-11
Available2016-01-11
Created2016-01-06
Modified2016-01-06
Pages2
File TypeAdobe Acrobat PDF
File Size432699
File SHA-256e710c86bf83d0c220af8fe1a63263d8085c29138f49b17fffb9bcc78e1a1bfbb
PDF Metadata AuthorRangLin
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 2868426
