RWF01 WIFI Module External Photos - FCC ID A7M-RWF01
FCC ID A7M-RWF01
External Photos
WIFI Module
Document preview loads when visible.
Document Details
| FCC ID | A7M-RWF01 |
|---|---|
| Document ID | 4291919 |
| Document Type | External Photos |
| Description | External Photos |
| Applicant | Shenzhen Reflying Electronic Co., Ltd. |
| Equipment Class | WIFI Module |
| Product Code | RWF01 |
| Application ID | XznCZ9yK/YKbCGqBF2FR9g== |
| Application Purpose | Original Equipment |
| Application Date | 2019-05-23 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0021357322 |
| Test Firm | TA Technology (Shanghai) Co., Ltd. |
| Certified By | Wen Luo Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2019-05-23 |
| Available | 2019-05-23 |
| Created | 2019-05-16 |
| Modified | 2019-05-16 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 773410 |
| File SHA-256 | 4327e3a270bbbbd49ecb6583eb044b6687c8844bacb8fb8d9380b53723b5d4e9 |
| PDF Metadata Author | W79558 |
| PDF Metadata Producer | WPS 文字 |
| FCC.gov Sources | FCC.gov 4291919, FCC.gov 4291933 |
