M2B0A DVD/Video Cassette Recorder Test Setup... - FCC ID A7RM2B0A

FCC ID A7RM2B0A

Test Photos

DVD/Video Cassette Recorder

by ORION ELECTRIC CO., LTD.

Document preview loads when visible.

Document Details

FCC IDA7RM2B0A
Document ID238710
Document TypeTest Setup Photos
DescriptionTest Photos
ApplicantORION ELECTRIC CO., LTD.
Equipment ClassDVD/Video Cassette Recorder
Product CodeM2B0A
Application IDBXRkgCCa1w9Gpj2rPFgweQ==
Application PurposeOriginal Equipment
Application Date2002-04-24
Frequency Range61.25-65.75 MHz
FRN0005917059
Test FirmUL Japan, Inc.
Certified ByKazunori Nishimura Manager of EMC Dept.
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2002-04-24
Available2002-04-24
Created2002-04-17
Modified2002-04-18
Pages8
File TypeAdobe Acrobat PDF
File Size141687
File SHA-256e2cc1b1bd352404bc462239c039a1d2ccbaeb922e21dffd500e35e986412e738
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows)
FCC.gov SourcesFCC.gov 238710
