IFIT3BT Multimedia Speaker System Block Diagram - FCC ID A8IIFIT-3BT
FCC ID A8IIFIT-3BT
Block Diagram
Multimedia Speaker System
Document preview loads when visible.
Document Details
| FCC ID | A8IIFIT-3BT |
|---|---|
| Document ID | 1882834 |
| Document Type | Block Diagram |
| Description | Block Diagram |
| Document Title | None |
| Applicant | Shenzhen DIVOOM Technology Co., Ltd. |
| Equipment Class | Multimedia Speaker System |
| Product Code | IFIT3BT |
| Application ID | aWXn28a00vhPfoR/pEhvWw== |
| Application Purpose | Original Equipment |
| Application Date | 2013-01-20 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0021371760 |
| Test Firm | Shenzhen Timeway Technology Consulting Co., Ltd. |
| Certified By | Jeffery Yao |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2013-01-20 |
| Available | 2013-01-20 |
| Created | 2013-01-16 |
| Modified | 2013-01-17 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 2255637 |
| File SHA-256 | d1fe5f64106ae938d04413875deccade5829dcdbf7c63227a03b6db6519b64a3 |
| PDF Metadata Author | None |
| PDF Metadata Creator | Canon SC1011 |
| PDF Metadata Producer | MP Navigator EX |
| FCC.gov Sources | FCC.gov 1882834 |
