BM20SPKXYNBZ Bluetooth Module Test Report - FCC ID A8TBM20SPKXYNBZ

FCC ID A8TBM20SPKXYNBZ

Test Report

Bluetooth Module

by Microchip Technology Inc.

Document preview loads when visible.

Document Details

FCC IDA8TBM20SPKXYNBZ
Document ID2747425
Document TypeTest Report
DescriptionTest Report
Document Title10050931 Microchip_BM20SPK_FCC 15.247
ApplicantMicrochip Technology Inc.
Equipment ClassBluetooth Module
Product CodeBM20SPKXYNBZ
Application ID9f2ZL4gcaouadc5EJhXElg==
Application PurposeOriginal Equipment
Application Date2015-09-15
Frequency Range2402-2480 MHz
FRN0001596279
Test FirmTUV Rheinland Taiwan Ltd.
Certified BySanjay Malani Staff Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2015-09-14
Available2015-09-15
Created2015-09-11
Modified2015-09-11
Pages51
File TypeAdobe Acrobat PDF
File Size3501669
File SHA-2560dfd92b6d220f0ffb446384e429cf25a687d283b812e2aa9089b45b95ad2a730
PDF Metadata AuthorChenRyan
PDF Metadata ProducerGPL Ghostscript 9.05 ChenRyan
FCC.gov SourcesFCC.gov 2747425
