FCC ID A8TBM71S2

Bluetooth Module

by Microchip Technology Inc.

Grantee Code: A8T   Product Code: BM71S2
Latest application date: 2016-01-05

Device Images

FCC ID A8TBM71S2 Internal Photos
Internal Photos
FCC ID A8TBM71S2 Users Manual
Users Manual
FCC ID A8TBM71S2 Users Manual
Users Manual
FCC ID A8TBM71S2 Users Manual
Users Manual
FCC ID A8TBM71S2 Users Manual
Users Manual
FCC ID A8TBM71S2 Test Setup Photos
Test Setup Photos
FCC ID A8TBM71S2 Test Setup Photos
Test Setup Photos
FCC ID A8TBM71S2 Test Setup Photos
Test Setup Photos
FCC ID A8TBM71S2 Test Setup Photos
Test Setup Photos
FCC ID A8TBM71S2 Test Setup Photos
Test Setup Photos
FCC ID A8TBM71S2 Test Setup Photos
Test Setup Photos

FCC ID Device Details

FCC IDA8TBM71S2
Mirrorsfcc.id | gov | fccid.ai
Grantee CodeA8T
Product CodeBM71S2
Applicant BusinessMicrochip Technology Inc. 🇺🇸
Related Domains microchip.com
Equipment ClassBluetooth Module
Test FirmTUV Rheinland Taiwan Ltd.

Operating Frequencies

Frequency RangeApplication PurposeFinal Action Date
2402-2480 MHzOriginal Equipment2016-01-05

Exhibits

DocumentTypeAvailableFile
Label n Location in manualID Label/Location Info2016-01-05PDF 320.1 KB
ManualUsers Manual2016-01-05PDF 745.6 KB
Internal PhotosInternal Photos2016-01-05PDF 300 KB
Ext. PhotosExternal Photos2016-01-05PDF 455.6 KB
label on packagingID Label/Location Info2016-01-05PDF 52.1 KB
Setup PhotoTest Setup Photos2016-01-05PDF 1.4 MB
Test ReportTest Report2016-01-05PDF 1.6 MB
Test ResultsTest Report2016-01-05PDF 2.3 MB
Conf. Req. LetterCover Letter(s)2016-01-05PDF 298.6 KB
Mod Appr. RequestCover Letter(s)2016-01-05PDF 850.1 KB
Exposure InfoRF Exposure Info2016-01-05PDF 79.7 KB
Block Diagram Metadata onlyBlock DiagramPDF 30.3 KB
Schematic Metadata onlySchematicsPDF 60 KB
Ant Desc Metadata onlyOperational DescriptionPDF 1.9 MB
OpDesc Metadata onlyOperational DescriptionPDF 59 KB

Application Information

Application IDdvm3MWWi+j5F/r30QEqHSQ==
Final Action Date2016-01-05
Application PurposeOriginal Equipment
Applicant FRN0001596279
ModelBM71S2
Frequency Range2402-2480 MHz
Equipment ClassDTS - Digital Transmission System
Device DescriptionBluetooth Module
Responsible PartySTEVE CALDWELL, Vice President, steve.caldwell@microchip.com , 480-792-7464
Test FirmSpring Wang, TUV Rheinland Taiwan Ltd., spring.wang@tuv.com , 886-2-2172-7000
TCB Emailrc@twn.tuv.com
TCB ScopeA4: UNII devices & low power transmitters using spread spectrum techniques
Short-Term ConfidentialityNo
Long-Term ConfidentialityYes
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Cognitive RadioNo
Authorization WaiverNo
Authorization Waiver ApprovedNo
Section 5301 CertificationYes
Related OET Knowledge DataBase InquiryNo
Grant CommentsOutput power listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. This transmitter is restricted for use with the specific antenna(s) tested in this application for Certification and must not be co-located or operating in conjunction with any other antenna or transmitters within a host device, except in accordance with FCC multi-transmitter product procedures. This module is approved for installation into mobile or/and portable host platforms.

Applications

Application IDDatePurpose
dvm3MWWi+j5F/r30QEqHSQ==2016-01-05Original Equipment

Equipment Authorization

FrequencyOutputRules
2402-2480 MHz0.001200015C

Grants

TCB Grant - Application dvm3MWWi+j5F/r30QEqHSQ==

TCB GRANT OF EQUIPMENT
AUTHORIZATION		 TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

  TUV Rheinland of North America, Inc.
1279 Quarry Lane Suite A
Pleasanton, CA 94566
 Date of Grant: 01/05/2016

Application Dated: 12/30/2015
Microchip Technology Inc.
2355 West Chandler Blvd.
CHANDLER, AZ 85224-6199

Attention: STEVE CALDWELL , Vice President

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  A8TBM71S2
Name of Grantee:  Microchip Technology Inc.
Equipment Class: Digital Transmission System
Notes: Bluetooth Module
Modular Type: Single Modular
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
15C 2402.0  -  2480.0 0.0012

Output power listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. This transmitter is restricted for use with the specific antenna(s) tested in this application for Certification and must not be co-located or operating in conjunction with any other antenna or transmitters within a host device, except in accordance with FCC multi-transmitter product procedures. This module is approved for installation into mobile or/and portable host platforms.
