FCC ID A8TBM78ABCDEFGH
Bluetooth Module
by Microchip Technology Inc.
Grantee Code: A8T Product Code: BM78ABCDEFGH
Latest application date: 2015-09-24
Device Images
FCC ID Device Details
| FCC ID | A8TBM78ABCDEFGH |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | A8T |
| Product Code | BM78ABCDEFGH |
| Applicant Business | Microchip Technology Inc. 🇺🇸 |
| Related Domains |  microchip.com |
| Equipment Class | Bluetooth Module |
| Test Firm | TUV Rheinland Taiwan Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-09-24 |
| 2402-2480 MHz | Original Equipment | 2015-09-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2015-09-24 | PDF 2.1 MB |
| Internal Photos | Internal Photos | 2015-09-24 | PDF 735.7 KB |
| Ext. Photos | External Photos | 2015-09-24 | PDF 735.7 KB |
| Label n Location | ID Label/Location Info | 2015-09-24 | PDF 37.7 KB |
| Setup Photo | Test Setup Photos | 2015-09-24 | PDF 894.5 KB |
| Setup Photo | Test Setup Photos | 2015-09-24 | PDF 894.8 KB |
| Test Report | Test Report | 2015-09-24 | PDF 1.9 MB |
| Test Report | Test Report | 2015-09-24 | PDF 2.7 MB |
| Test Results | Test Report | 2015-09-24 | PDF 2.3 MB |
| Test Results | Test Report | 2015-09-24 | PDF 3.5 MB |
| Conf. Req. Letter | Cover Letter(s) | 2015-09-24 | PDF 38.7 KB |
| Mod Appr. Request | Cover Letter(s) | 2015-09-24 | PDF 145.4 KB |
| Exposure Info | RF Exposure Info | 2015-09-24 | PDF 27.4 KB |
| Exposure Info | RF Exposure Info | 2015-09-24 | PDF 27.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 153.6 KB | |
| Schematic Metadata only | Schematics | PDF 212 KB | |
| Ant Desc Metadata only | Operational Description | PDF 307.7 KB | |
| OpDesc Metadata only | Operational Description | PDF 18.4 KB |
Application Information
| Application ID | pdM4qq/DxBCyrx282Vnh+Q== |
|---|---|
| Final Action Date | 2015-09-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0001596279 |
| Model | BM78ABCDEFGH |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Bluetooth Module |
| Responsible Party | STEVE CALDWELL, Vice President, steve.caldwell@microchip.com , 480-792-7464 |
| Test Firm | Spring Wang, TUV Rheinland Taiwan Ltd., spring.wang@tuv.com  , 886-2-2172-7000 |
| TCB Email | rc@twn.tuv.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. This transmitter is restricted for use with the specific antenna(s) tested in this application for Certification and must not be co-located or operating in conjunction with any other antenna or transmitters within a host device, except in accordance with FCC multi-transmitter product procedures. |
