YZM Wireless audio link Teardown Internal Photos - FCC ID A94YZM

FCC ID A94YZM

Internal photos

Wireless audio link

by Bose Corporation

Document preview loads when visible.

Document Details

FCC IDA94YZM
Document ID534941
Document TypeInternal Photos
DescriptionInternal photos
Document TitleFCC ID A94WLM1 (Freebird) product photos
ApplicantBose Corporation
Equipment ClassWireless audio link
Product CodeYZM
Application IDsv4eUqW6dGPU0Dwd8BBIUw==
Application PurposeOriginal Equipment
Application Date2005-04-21
Frequency Range2401.9-2478.8 MHz
FRN0006179345
Test FirmBose Corporation
Certified ByJon J. Kanter Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date05/20/2005
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-04-21
Available2005-05-20
Created2005-02-22
Modified2005-03-07
Pages4
File TypeAdobe Acrobat PDF
File Size484597
File SHA-256e0a34beb1fb6d9aa487c1c26402cd2c3d3dc1c2c5e83223f739c62e2eeef34db
PDF Metadata Authorpb13659
PDF Metadata ProducerAcrobat Distiller 5.0.5 (Windows) pb13659
FCC.gov SourcesFCC.gov 534941
