2000432 Teardown Internal Photos - FCC ID AAO2000432

FCC ID AAO2000432

Front Panel Rear View

2000432

by RadioShack Corporation

Front Panel Rear View

Document Details

FCC IDAAO2000432
Document ID34998
Document TypeInternal Photos
DescriptionFront Panel Rear View
ApplicantRadioShack Corporation
Equipment Class2000432
Product Code2000432
Application IDWU5aGBcHuaSHM369XuozvQ==
Application PurposeOriginal Equipment
Application Date1999-06-22
Frequency Range108-174 MHz
FRN0027478072
Test FirmUniden Corporation
Certified ByJames R. Haynes Vice President, Engineering and Regulatory Affairs
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted1999-04-29
Available1999-06-22
Pages0
File TypeJPEG Image
File Size141621
File SHA-25690a8d02c4395b6b321b343ada57db5b2b4441b8a97b3410edbf3f3f4e70d8aa1
FCC.gov SourcesFCC.gov 34998
