2101679 CB Transceiver Label Diagram - FCC ID AAO2101679

FCC ID AAO2101679

ID Label Location

CB Transceiver

by RadioShack Corporation

ID Label Location

Document Details

FCC IDAAO2101679
Document ID119563
Document TypeID Label/Location Info
DescriptionID Label Location
ApplicantRadioShack Corporation
Equipment ClassCB Transceiver
Product Code2101679
Application IDDb+cLsCReT2GJBowTdrj1w==
Application PurposeOriginal Equipment
Application Date2000-12-06
Frequency Range26.965-27.405 MHz
FRN0027478072
Test FirmHyak Laboratories, Inc.
Certified ByRowland S. Johnson President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2000-10-03
Available2000-12-06
Pages0
File TypeJPEG Image
File Size162704
File SHA-2563ff023dd6bfb08affff3b3e04195aa2303c200e6b2e5cda355ea0f44e79a203d
FCC.gov SourcesFCC.gov 119563
