99FT7012 Base Station Test Setup Photos - FCC ID ABZ99FT7012
FCC ID ABZ99FT7012
Test Setup Photos
Base Station
Document preview loads when visible.
Document Details
| FCC ID | ABZ99FT7012 |
|---|---|
| Document ID | 74040 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | Base.PDF |
| Applicant | Motorola Solutions, Inc. |
| Equipment Class | Base Station |
| Product Code | 99FT7012 |
| Application ID | 2fAfrZXKg2/CZ7mXvisBHg== |
| Application Purpose | Original Equipment |
| Application Date | 2000-03-07 |
| Frequency Range | 1920-1930 MHz |
| FRN | 0025009739 |
| Test Firm | Communication Certification Lab. |
| Certified By | Dale Rublaitus Engineering Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 1999-12-06 |
| Available | 2000-03-07 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 240375 |
| File SHA-256 | 695e786f50696c0eda3f0d5652602bbb03312214aa321f287a8eccc73f2c1301 |
| PDF Metadata Author | Unknown |
| PDF Metadata Producer | Microsoft Word Acrobat PDFWriter 3.02 for Windows |
| FCC.gov Sources | FCC.gov 74040 |
