927119AHP Teardown Internal Photos - FCC ID ACJ927119AHP
FCC ID ACJ927119AHP
9
927119AHP
Document preview loads when visible.
Document Details
| FCC ID | ACJ927119AHP |
|---|---|
| Document ID | 62494 |
| Document Type | Internal Photos |
| Description | 9 |
| Applicant | Panasonic Corporation of North America |
| Equipment Class | 927119AHP |
| Product Code | 927119AHP |
| Application ID | OB6sOxavObdmOgAYBDrsgA== |
| Application Purpose | Class II Permissive Change |
| Application Date | 1998-10-05 |
| Frequency Range | 60-72 MHz |
| FRN | 0003762242 |
| Certified By | K. Ishikawa Sr. Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 1999-10-07 |
| Available | 1998-10-05 |
| Created | 2001-05-21 |
| Modified | 2001-05-22 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 185756 |
| File SHA-256 | 56c7661e6b06fceef86fa0b2b8e499c9c42c7879fed488edd5e4d1d5e1c87ec0 |
| PDF Metadata Producer | Acrobat Distiller 4.0 for Windows |
| FCC.gov Sources | FCC.gov 62494 |
