9TGRI23B RFID Module Label Diagram - FCC ID ACJ9TGRI23B

FCC ID ACJ9TGRI23B

Label Sample & Label Location (Module)

RFID Module

by Panasonic Corporation of North America

Document preview loads when visible.

Document Details

FCC IDACJ9TGRI23B
Document ID6970208
Document TypeID Label/Location Info
DescriptionLabel Sample & Label Location (Module)
ApplicantPanasonic Corporation of North America
Equipment ClassRFID Module
Product Code9TGRI23B
Application IDTSjZvMb5NTcNNLxDccFEQw==
Application PurposeOriginal Equipment
Application Date2023-12-29
Frequency Range13.56 MHz
FRN0003762242
Test FirmBureau Veritas CPS(H.K.) Ltd., Taoyuan Branch
Certified ByJenny Nien Specialist
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/28/2024
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2023-12-07
Available2023-12-29
Created2023-11-07
Modified2023-11-14
Pages1
File TypeAdobe Acrobat PDF
File Size182620
File SHA-2565fa69bbe671a4d095bdb29c65093222ec121ca88fe5a914fafa2d758095c577f
PDF Metadata AuthorSuzuki Tsutomu (鈴木 努)
PDF Metadata ProducerMicrosoft® Word for Microsoft 365 Suzuki Tsutomu (鈴木 努)
FCC.gov SourcesFCC.gov 6970208
