EAHAZ70W Digital Wireless Stereo... - FCC ID ACJ-EAH-AZ70W

FCC ID ACJ-EAH-AZ70W

11. Test Setup Photos

Digital Wireless Stereo Earphones

by Panasonic Corporation of North America

Document preview loads when visible.

Document Details

FCC IDACJ-EAH-AZ70W
Document ID4647123
Document TypeTest Setup Photos
Description11. Test Setup Photos
Document TitleMeasurement Report
ApplicantPanasonic Corporation of North America
Equipment ClassDigital Wireless Stereo Earphones
Product CodeEAHAZ70W
Application IDkxnTgAadY4XpDDugt9nAvA==
Application PurposeOriginal Equipment
Application Date2020-03-13
Frequency Range2402-2480 MHz
FRN0007403181
Test FirmBTL Inc.
Certified ByMandy Wang Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/09/2020
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2020-03-12
Available2020-09-09
Created2020-02-19
Modified2020-02-19
Pages4
File TypeAdobe Acrobat PDF
File Size1846955
File SHA-256dc2bba80ea87e83f16129ac3ef14d4d6af1ec5cd7084d1a553715ff051ba451b
PDF Metadata AuthorReportServer
PDF Metadata ProducerReportServer Adobe PDF Library 19.8.103
FCC.gov SourcesFCC.gov 4647123, FCC.gov 4647117
