AP4U01 Microwave Oven Test Report - FCC ID ACLAP4U01

FCC ID ACLAP4U01

Description and Test Data Report

Microwave Oven

by Panasonic Corporation of North America

Document preview loads when visible.

Document Details

FCC IDACLAP4U01
Document ID77398
Document TypeTest Report
DescriptionDescription and Test Data Report
ApplicantPanasonic Corporation of North America
Equipment ClassMicrowave Oven
Product CodeAP4U01
Application IDev89qLN9/6OF9xOcuYpy6g==
Application PurposeOriginal Equipment
Application Date2000-01-12
Frequency Range2450 MHz
FRN0027086172
Test FirmPanasonic Industrial Company
Certified ByJames Kingsley Senior Engineer, Product Safety
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted1999-12-20
Available2000-01-12
Created2001-05-07
Modified2001-05-07
Pages5
File TypeAdobe Acrobat PDF
File Size8203
File SHA-256fd043ebcf94b7bfb1adcc1374a1f4262ddfe75f7abaea80595de1b4b0015364a
PDF Metadata ProducerAcrobat Distiller 4.0 for Windows
FCC.gov SourcesFCC.gov 77398
