FCC ID ACQ-IP810W
Set-top box
by ARRIS
Grantee Code: ACQ Product Code: IP810W
Latest application date: 2015-10-16
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2015-10-16 |
| 2405-2480 MHz | Original Equipment | 2015-10-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-10-16 | PDF 177.3 KB |
| Internal Photos | Internal Photos | 2015-10-16 | PDF 464.5 KB |
| External Photos | External Photos | 2015-10-16 | PDF 550.4 KB |
| Label | ID Label/Location Info | 2015-10-16 | PDF 197.9 KB |
| Label Location | ID Label/Location Info | 2015-10-16 | PDF 388.9 KB |
| Test Set Up Photos | Test Setup Photos | 2015-10-16 | PDF 271.5 KB |
| Test Report | Test Report | 2015-10-16 | PDF 2.1 MB |
| Test Report | Test Report | 2015-10-16 | PDF 3.3 MB |
| Authority to Act as Agent | Cover Letter(s) | 2015-10-16 | PDF 55.5 KB |
| Confidentiality | Cover Letter(s) | 2015-10-16 | PDF 101 KB |
| RF Safety | RF Exposure Info | 2015-10-16 | PDF 22.2 KB |
| RF Safety | RF Exposure Info | 2015-10-16 | PDF 26.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 81 KB | |
| Schematics Metadata only | Schematics | PDF 462.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 1 MB |
Application Information
| Application ID | FVtcZX8Pny923XTOjFzcaw== |
|---|---|
| Final Action Date | 2015-10-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0007379399 |
| Model | IP810W |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Set-top box |
| Responsible Party | Jorge Villarreal, Jorge.Villarreal@arris.com  , 215-323-1697 |
| Agent | Jenny Jenny Jenny, Nemko USA, jenny.gibbs@nemko.com  |
| Test Firm | Charles Neal, Nemko USA, Inc. - San Diego EMC Division, charles.neal@nemko.com , 613-737-9680 x239 |
| TCB Email | stuart.beck@nemko.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| FVtcZX8Pny923XTOjFzcaw== | 2015-10-16 | Original Equipment |
| EpBgyb3v+wahpyQ45OzdRQ== | 2015-10-16 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application FVtcZX8Pny923XTOjFzcaw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| ARRIS |
| 101 Tournament Drive |
| Horsham, PA 19044 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP810W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Set-top box |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.107 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.093 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application FVtcZX8Pny923XTOjFzcaw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 101 Tournament Drive Horsham, PA 19044 United States |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP810W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Set-top box |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.107 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.093 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| ARRIS |
| 101 Tournament Drive |
| Horsham, PA 19044 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP810W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Set-top box |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2405.0 - 2480.0 | 0.0014 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application EpBgyb3v+wahpyQ45OzdRQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 101 Tournament Drive Horsham, PA 19044 United States |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP810W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Set-top box |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2405.0 - 2480.0 | 0.0014 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
