FCC ID ACQ-IP815W
Set-top box
by ARRIS
Grantee Code: ACQ Product Code: IP815W
Latest application date: 2018-05-02
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2018-05-02 |
| 5180-5240 MHz | Original Equipment | 2015-10-16 |
| 2405-2480 MHz | Original Equipment | 2015-10-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-10-16 | PDF 177.3 KB |
| Internal Photos | Internal Photos | 2015-10-16 | PDF 1.3 MB |
| External Photos | External Photos | 2015-10-16 | PDF 1.8 MB |
| Label | ID Label/Location Info | 2015-10-16 | PDF 145.8 KB |
| Label | ID Label/Location Info | 2015-10-16 | PDF 382.3 KB |
| Label Location | ID Label/Location Info | 2015-10-16 | PDF 382.3 KB |
| Test Setup Photos | Test Setup Photos | 2018-05-02 | PDF 619.9 KB |
| Test Set Up Photos | Test Setup Photos | 2015-10-16 | PDF 271.7 KB |
| Test report | Test Report | 2018-05-02 | PDF 2.8 MB |
| Test Report | Test Report | 2015-10-16 | PDF 2.7 MB |
| Cover Letters | Cover Letter(s) | 2018-05-02 | PDF 108.7 KB |
| Authority to Act as Agent | Cover Letter(s) | 2015-10-16 | PDF 55.5 KB |
| Confidentiality | Cover Letter(s) | 2015-10-16 | PDF 75.6 KB |
| RF Exposure info | RF Exposure Info | 2018-05-02 | PDF 236.7 KB |
| RF Safety | RF Exposure Info | 2015-10-16 | PDF 26.6 KB |
| RF Safety | RF Exposure Info | 2015-10-16 | PDF 22.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 81 KB | |
| Schematics Metadata only | Schematics | PDF 292.6 KB | |
| Schematics Metadata only | Schematics | PDF 462.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 116.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 70.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 60.7 KB |
Application Information
| Application ID | tpIdf9mm46GDIGtbUz3+0A== |
|---|---|
| Final Action Date | 2018-05-02 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007379399 |
| Model | IP815W |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Set-top box |
| Responsible Party | Jorge Villarreal, Jorge.Villarreal@arris.com  , 215-323-1697 |
| Test Firm | Charles Neal, Nemko Canada Inc. (Ottawa), charles.neal@nemko.com  , 613-737-9680 |
| TCB Email | Stuart.Beck@nemko.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.This device complies with the Dynamic Frequency Selection (DFS) requirements of FCC 03-287 as a Client-only without Radar Detection. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| tpIdf9mm46GDIGtbUz3+0A== | 2018-05-02 | Class II permissive change or modification of presently authorized equipment |
| aJ0Trcj+FWyIl0E5rkbEqA== | 2015-10-16 | Original Equipment |
| VshY39XUIOO/o50f8P3PFA== | 2015-10-16 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application VshY39XUIOO/o50f8P3PFA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| ARRIS |
| 101 Tournament Drive |
| Horsham, PA 19044 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP815W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Set-top box |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2405.0 - 2480.0 | 0.0012 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application VshY39XUIOO/o50f8P3PFA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 101 Tournament Drive Horsham, PA 19044 United States |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP815W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Set-top box |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2405.0 - 2480.0 | 0.0012 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 05/02/2018 Application Dated: 05/02/2018 |
| ARRIS |
| 101 Tournament Drive |
| Horsham, PA 19044 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP815W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Set-top box |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.107 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.221 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.238 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.093 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.This device complies with the Dynamic Frequency Selection (DFS) requirements of FCC 03-287 as a Client-only without Radar Detection. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application tpIdf9mm46GDIGtbUz3+0A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 101 Tournament Drive Horsham, PA 19044 United States |
Date of Grant: 05/02/2018 Application Dated: 05/02/2018 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP815W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Set-top box |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.107 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.221 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.238 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.093 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.This device complies with the Dynamic Frequency Selection (DFS) requirements of FCC 03-287 as a Client-only without Radar Detection. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| ARRIS |
| 101 Tournament Drive |
| Horsham, PA 19044 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP815W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Set-top box |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.107 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.093 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application aJ0Trcj+FWyIl0E5rkbEqA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 101 Tournament Drive Horsham, PA 19044 United States |
Date of Grant: 10/16/2015 Application Dated: 10/16/2015 |
| Attention: Jorge Villarreal |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ACQ-IP815W |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Set-top box |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.107 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.093 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
