ECHOII Digital Pen Test Setup Photos - FCC ID ADM-ECHOII
FCC ID ADM-ECHOII
Test Setup Photo
Digital Pen
Document preview loads when visible.
Document Details
| FCC ID | ADM-ECHOII |
|---|---|
| Document ID | 5306341 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photo |
| Document Title | ()_Test Setup Photo |
| Applicant | Anoto Korea Corp. |
| Equipment Class | Digital Pen |
| Product Code | ECHOII |
| Application ID | ifbw0h/vhdA5MADq6wiD9A== |
| Application Purpose | Original Equipment |
| Application Date | 2021-06-23 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0027755479 |
| Test Firm | CTK Co., Ltd. |
| Certified By | Changhoon Shin |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2021-06-23 |
| Available | 2021-06-23 |
| Created | 2021-06-08 |
| Modified | 2021-06-08 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 796792 |
| File SHA-256 | bfb62fbd809a5538cacb0bd704b7da79a13ba33653c36d4b991d8d418a615d3e |
| PDF Metadata Author | GWANYONG K |
| PDF Metadata Producer | Acrobat Distiller 9.0.0 (Windows) GWANYONG K |
| FCC.gov Sources | FCC.gov 5306341, FCC.gov 5306312 |
