U9W30X WiFi Module User Manual - FCC ID ADTU9W30X
FCC ID ADTU9W30X
05 User Manual
WiFi Module
Document preview loads when visible.
Document Details
| FCC ID | ADTU9W30X |
|---|---|
| Document ID | 3409898 |
| Document Type | Users Manual |
| Description | 05 User Manual |
| Applicant | Funai Electric Co Ltd |
| Equipment Class | WiFi Module |
| Product Code | U9W30X |
| Application ID | Rj1nNHHQNm42631te0oiZA== |
| Application Purpose | Original Equipment |
| Application Date | 2017-06-01 |
| Frequency Range | 5180-5320 MHz |
| FRN | 0024682353 |
| Test Firm | KEC Electronic Industry Development Center |
| Certified By | Yoshihisa Maeda Project Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2017-06-01 |
| Available | 2017-06-01 |
| Created | 2017-05-31 |
| Modified | 2017-05-31 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 145737 |
| File SHA-256 | fda283f79223883d8ddbbf447b04163317c1913967f16f322311afab617c2434 |
| PDF Metadata Author | Fujiwara, Rie Underwriters Laboratories Inc. |
| PDF Metadata Producer | Fujiwara, Rie Adobe PDF Library 10.0 |
| FCC.gov Sources | FCC.gov 3409898, FCC.gov 3409865 |
