A50749R BATTLE TANK - RECEIVER Schematics - FCC ID AEKA50749R

FCC ID AEKA50749R

SCHEMATICS

BATTLE TANK - RECEIVER

by Taiyo Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDAEKA50749R
Document ID555185
Document TypeSchematics
DescriptionSCHEMATICS
ApplicantTaiyo Co., Ltd.
Equipment ClassBATTLE TANK - RECEIVER
Product CodeA50749R
Application IDByaWCMwlm1x56AUvQdEEIg==
Application PurposeOriginal Equipment
Application Date2005-06-23
Frequency Range49.82-49.9 MHz
FRN0005882246
Test FirmTimco Engineering, Inc.
Certified ByAYUMI WATANABE MARKETING OPERATOR
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-06-23
Available2005-06-23
Created2005-06-21
Modified2005-06-21
Pages1
File TypeAdobe Acrobat PDF
File Size103586
File SHA-256d4e82466631946ba1a66701e11f7dad1a2a7f43be7a6ebcf2fb8bbaf514bc8fc
PDF Metadata ProducerAdobe Acrobat 6.02 Adobe Acrobat 6.02 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 555185
