FCC ID AJDK095
Car Audio with Bluetooth / WLAN
by Pioneer Corporation
Grantee Code: AJD Product Code: K095
Latest application date: 2016-04-05
Device Images
FCC ID Device Details
| FCC ID | AJDK095 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | AJD |
| Product Code | K095 |
| Applicant Business | Pioneer Corporation 🇯🇵 |
| Related Domains |  post.pioneer.co.jp |
| Equipment Class | Car Audio with Bluetooth / WLAN |
| Test Firm | UL Japan, Inc. Kashima EMC Lab. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-04-05 |
| 2412-2462 MHz | Original Equipment | 2016-04-05 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users manual | Users Manual | 2016-10-02 | PDF 153.1 KB |
| Internal photos | Internal Photos | 2016-10-02 | PDF 437.6 KB |
| External photos | External Photos | 2016-10-02 | PDF 372.4 KB |
| ID labe location | ID Label/Location Info | 2016-04-05 | PDF 96.6 KB |
| ID label | ID Label/Location Info | 2016-04-05 | PDF 133.7 KB |
| ID label location | ID Label/Location Info | 2016-04-05 | PDF 96.6 KB |
| Test setup photos | Test Setup Photos | 2016-10-02 | PDF 153.2 KB |
| Test setup photos | Test Setup Photos | 2016-10-02 | PDF 156.8 KB |
| Test report | Test Report | 2016-04-05 | PDF 689.1 KB |
| Test report(DSS) | Test Report | 2016-04-05 | PDF 823.7 KB |
| Authorization letter | Cover Letter(s) | 2016-04-05 | PDF 517.7 KB |
| Confidentiality letter(long) | Cover Letter(s) | 2016-04-05 | PDF 450.6 KB |
| Confidentiality letter(short) | Cover Letter(s) | 2016-04-05 | PDF 480.2 KB |
| Power of attorney | Cover Letter(s) | 2016-04-05 | PDF 18.4 KB |
| Power of attornney | Cover Letter(s) | 2016-04-05 | PDF 18.4 KB |
| RF EX(DSS) | RF Exposure Info | 2016-04-05 | PDF 31.6 KB |
| RF EX(DSS+DTS) | RF Exposure Info | 2016-04-05 | PDF 63.8 KB |
| RF EX(DTS) | RF Exposure Info | 2016-04-05 | PDF 10.8 KB |
| Block diagram Metadata only | Block Diagram | PDF 186.9 KB | |
| Block diagram(RF) Metadata only | Block Diagram | PDF 149.3 KB | |
| Schematics Metadata only | Schematics | PDF 131 KB | |
| Operational description(Antenna) Metadata only | Operational Description | PDF 77.7 KB | |
| Operational description(Hopping) Metadata only | Operational Description | PDF 25.8 KB | |
| Operational description(Module) Metadata only | Operational Description | PDF 2.4 MB | |
| Operational description(Spec) Metadata only | Operational Description | PDF 2.3 MB |
Application Information
| Application ID | n4JkE9mLEfJk8DXbTA7quQ== |
|---|---|
| Final Action Date | 2016-04-05 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0030786412 |
| Model | K095 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Car Audio with Bluetooth / WLAN |
| Responsible Party | Takashi Tsuzura, Manager, takashi_tsuzura@post.pioneer.co.jp , 81-49-228-6220 |
| Agent | Yoshihisa Yoshihisa Yoshihisa, UL Japan, Inc., Yoshihisa.Maeda@ul.com  , 81-596-24-8999 |
| Technical Contact | Masanori Nishiyama, UL Japan, Inc., Masanori.Nishiyama@ul.com , 81-478-88-6500 |
| Test Firm | Tetsuya Hashimoto, UL Japan, Inc. Kashima EMC Lab., Tetsuya.Hashimoto@jp.ul.com  , +81-596-24-8116 |
| TCB Email | emc.jp@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 10/02/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is Conducted(Peak). The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
