FCC ID AK8WS001
Wireless Module
by Sony Group Corporation
Grantee Code: AK8 Product Code: WS001
Latest application date: 2015-12-04
Device Images
FCC ID Device Details
| FCC ID | AK8WS001 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | AK8 |
| Product Code | WS001 |
| Applicant Business | Sony Group Corporation 🇯🇵 |
| Related Domains |  jp.sony.com |
| Equipment Class | Wireless Module |
| Test Firm | UL Japan, Inc. Shonan EMC EMC Lab. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-12-04 |
| 5180-5240 MHz | Original Equipment | 2013-11-18 |
| 5736-5814 MHz | Original Equipment | 2013-11-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| (Short-Term Confidential) User Manual_REV | Users Manual | 2014-03-18 | PDF 604.7 KB |
| (Short-Term Confidential) Internal Photo | Internal Photos | 2014-03-18 | PDF 114.5 KB |
| (Short-Term Confidential) External Photo | External Photos | 2014-03-18 | PDF 122.1 KB |
| Label & Location | ID Label/Location Info | 2013-11-18 | PDF 45.7 KB |
| FCC Test Setup Photo_NII | Test Setup Photos | 2015-12-04 | PDF 774.8 KB |
| (Short-Term Confidential) FCC Test Setup Photo_15C_REV | Test Setup Photos | 2014-03-18 | PDF 670.9 KB |
| (Short-Term Confidential) FCC Test Setup Photo_15E_REV | Test Setup Photos | 2014-03-18 | PDF 671 KB |
| FCC Test Report_NII | Test Report | 2015-12-04 | PDF 510.5 KB |
| FCC Report_15C_REV | Test Report | 2013-11-18 | PDF 3 MB |
| FCC Report_15E_REV | Test Report | 2013-11-18 | PDF 2 MB |
| FCC Authorization Letter | Cover Letter(s) | 2015-12-04 | PDF 25.8 KB |
| FCC Class II Permissive Change Letter | Cover Letter(s) | 2015-12-04 | PDF 41.9 KB |
| FCC LMA Letter | Cover Letter(s) | 2015-12-04 | PDF 23.2 KB |
| FCC Request for Confidentiality Letter | Cover Letter(s) | 2015-12-04 | PDF 20.5 KB |
| FCC Special Power of Attorney | Cover Letter(s) | 2015-12-04 | PDF 28 KB |
| FCC Authorization Letter | Cover Letter(s) | 2013-11-18 | PDF 234.9 KB |
| FCC LMA Letter | Cover Letter(s) | 2013-11-18 | PDF 307 KB |
| FCC Request for Confidentiality Letter | Cover Letter(s) | 2013-11-18 | PDF 233.5 KB |
| FCC Request for Short-term Confidentiality Letter | Cover Letter(s) | 2013-11-18 | PDF 236.2 KB |
| FCC Special Power of Attorney | Cover Letter(s) | 2013-11-18 | PDF 131.6 KB |
| FCC RF Exposure_NII | RF Exposure Info | 2015-12-04 | PDF 51.2 KB |
| FCC RF Exposure sheet_15C | RF Exposure Info | 2013-11-18 | PDF 52.6 KB |
| FCC RF Exposure sheet_15E | RF Exposure Info | 2013-11-18 | PDF 53.4 KB |
| (Confidential) Theory of Operation-Software Security Metadata only | SDR Software/Security Inf | PDF 21.9 KB |
Application Information
| Application ID | QDGjwDDwkkDhaeBwKdZmSA== |
|---|---|
| Final Action Date | 2015-12-04 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0003739166 |
| Model | WS001 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless Module |
| Responsible Party | Kazuyuki Hori, Chief EMC/RF Compliance Specialist, qec-pcom-emcrf@jp.sony.com , 81-50-3141-6220 |
| Agent | Yoshihisa Yoshihisa Yoshihisa, UL Japan, Inc., Yoshihisa.Maeda@ul.com  , 81-596-24-8999 |
| Technical Contact | Toyokazu Imamura, UL Japan, Inc., Toyokazu.Imamura@ul.com , 81-463-50-6400 |
| Test Firm | Tetsuya Hashimoto, UL Japan, Inc. Shonan EMC EMC Lab., Tetsuya.Hashimoto@jp.ul.com  , +81-596-24-8116 |
| TCB Email | emc.jp@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II Permissive Change based on FCC14-30. Limited Modular Approval. Output power listed is Conducted. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| QDGjwDDwkkDhaeBwKdZmSA== | 2015-12-04 | Class II permissive change or modification of presently authorized equipment |
| mvqcsSE7mIBm0nlYCiRgyQ== | 2013-11-18 | Original Equipment |
| 03bqNWqNNb39t5DRFz1+fA== | 2013-11-18 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application QDGjwDDwkkDhaeBwKdZmSA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 12/04/2015 Application Dated: 12/04/2015 |
| Sony Group Corporation |
| 1-7-1 Konan |
| Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Kazuyuki Hori , Chief EMC/RF Compliance Specialist |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AK8WS001 |
| Name of Grantee: | Sony Group Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.0095 | ||
| 38 CC | 15E | 5736.0 - 5814.0 | 0.0104 |
| Class II Permissive Change based on FCC14-30. Limited Modular Approval. Output power listed is Conducted. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application QDGjwDDwkkDhaeBwKdZmSA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Group Corporation 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 12/04/2015 Application Dated: 12/04/2015 |
| Attention: Kazuyuki Hori , Chief EMC/RF Compliance Specialist |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AK8WS001 |
| Name of Grantee: | Sony Group Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.0095 | ||
| 38 CC | 15E | 5736.0 - 5814.0 | 0.0104 |
| Class II Permissive Change based on FCC14-30. Limited Modular Approval. Output power listed is Conducted. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 11/18/2013 Application Dated: 11/18/2013 |
| Sony Corporation |
| 1-7-1 Konan |
| Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Ryo Takata , Senior Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AK8WS001 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15E | 5180.0 - 5240.0 | 0.0095 |
| Limited Modular Approval. Output power listed is Conducted. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. Operations in 5.15-5.25 GHz band are for indoor use only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application mvqcsSE7mIBm0nlYCiRgyQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 11/18/2013 Application Dated: 11/18/2013 |
| Attention: Ryo Takata , Senior Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AK8WS001 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15E | 5180.0 - 5240.0 | 0.0095 |
| Limited Modular Approval. Output power listed is Conducted. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. Operations in 5.15-5.25 GHz band are for indoor use only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 11/18/2013 Application Dated: 11/18/2013 |
| Sony Corporation |
| 1-7-1 Konan |
| Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Ryo Takata , Senior Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AK8WS001 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 5736.0 - 5814.0 | 0.0276 |
| Limited Modular Approval. Output power listed is Conducted. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application 03bqNWqNNb39t5DRFz1+fA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 11/18/2013 Application Dated: 11/18/2013 |
| Attention: Ryo Takata , Senior Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AK8WS001 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 5736.0 - 5814.0 | 0.0276 |
| Limited Modular Approval. Output power listed is Conducted. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
