29383210 UHF FM Mobile Transceiver Schematics - FCC ID ALH29383210

FCC ID ALH29383210

Schematic

UHF FM Mobile Transceiver

by Kenwood USA Corporation

Document preview loads when visible.

Document Details

FCC IDALH29383210
Document ID100814
Document TypeSchematics
DescriptionSchematic
ApplicantKenwood USA Corporation
Equipment ClassUHF FM Mobile Transceiver
Product Code29383210
Application ID0+1L4WtcKMwbGtIJT8Tlvw==
Application PurposeOriginal Equipment
Application Date2000-12-11
Frequency Range450-490 MHz
FRN0004356960
Test FirmM. Flom Associates, Inc.
Certified ByMorton Flom P. Eng., President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2000-05-17
Available2000-12-11
Created2000-04-18
Modified2000-04-18
Pages1
File TypeAdobe Acrobat PDF
File Size30731
File SHA-256fc5cd7b3aad54bc80539a40bcd64aba26e207b3289443a7cfc19f3f424f2c24f
PDF Metadata AuthorKENWOOD
PDF Metadata CreatorMicrosoft Word 9.0
PDF Metadata ProducerAcrobat Distiller 4.05 for Windows
FCC.gov SourcesFCC.gov 100814, FCC.gov 100817, FCC.gov 100816, FCC.gov 100815, FCC.gov 100813, FCC.gov 100812
