36413110 VHF FM Transceiver Label Diagram - FCC ID ALH36413110

FCC ID ALH36413110

Label Drawing

VHF FM Transceiver

by Kenwood USA Corporation

Document preview loads when visible.

Document Details

FCC IDALH36413110
Document ID329038
Document TypeID Label/Location Info
DescriptionLabel Drawing
ApplicantKenwood USA Corporation
Equipment ClassVHF FM Transceiver
Product Code36413110
Application IDjVIF6e4qGjd7LzJQhjluSA==
Application PurposeOriginal Equipment
Application Date2003-08-21
Frequency Range136-174 MHz
FRN0004356960
Test FirmM. Flom Associates, Inc.
Certified ByMorton Flom P. Eng., President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-05-29
Available2003-08-21
Created2003-05-15
Modified2003-05-15
Pages1
File TypeAdobe Acrobat PDF
File Size637094
File SHA-256b0b461ed9f15cf4fee14c5e5fb1f2a05d0ed0cabaf1ed9cfc247cc8b0aadc71a
PDF Metadata ProducerAcrobat 4.05 Import Plug-in for Windows Acrobat 4.05 Import Plug-in for Windows
FCC.gov SourcesFCC.gov 329038
