UC702 2.4 GHz Spread Spectrum Cordless... - FCC ID AMWUC702

FCC ID AMWUC702

Compatible Test Report Section 8

2.4 GHz Spread Spectrum Cordless Telephone

by Uniden America Corporation

Document preview loads when visible.

Document Details

FCC IDAMWUC702
Document ID88179
Document TypeTest Report
DescriptionCompatible Test Report Section 8
ApplicantUniden America Corporation
Equipment Class2.4 GHz Spread Spectrum Cordless Telephone
Product CodeUC702
Application IDYXfxI45e1x6vTXiNYrTvtg==
Application PurposeOriginal Equipment
Application Date2000-08-25
Frequency Range2406.912-2466.304 MHz
FRN0001657303
Test FirmCompatible Electronics
Certified ByJames R. Haynes Vice President, Engineering & Regulatory Affairs
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2000-02-25
Available2000-08-25
Created2000-02-23
Modified2000-02-23
Pages9
File TypeAdobe Acrobat PDF
File Size424212
File SHA-25667e05dbf3608aa1bb7cc4351da2334d2b01e7379d2b232ecc54a1ad3d03a44ef
PDF Metadata ProducerPhotoshop PDF Plug-in 1.0 Photoshop PDF Plug-in 1.0
FCC.gov SourcesFCC.gov 88179
