VNCBDC80211B Test Setup Photos - FCC ID ANOVNCBDC80211B

FCC ID ANOVNCBDC80211B

Test Setup Photos

VNCBDC80211B

by International Business Machines Corporation

Document preview loads when visible.

Document Details

FCC IDANOVNCBDC80211B
Document ID155852
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title.橡.Photos.PDF
ApplicantInternational Business Machines Corporation
Equipment ClassVNCBDC80211B
Product CodeVNCBDC80211B
Application ID+7h603dXzFHGou7HpDErIg==
Application PurposeOriginal Equipment
Application Date2001-10-09
Frequency Range2402-2480 MHz
FRN0004279931
Test FirmIBM Japan
Certified ByAkihisa Sakurai Manager, EMC Engineering
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralYes
Grant Deferral Date10/08/2001
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-06-22
Available2001-10-09
Created2001-06-22
Modified2001-06-22
Pages5
File TypeAdobe Acrobat PDF
File Size776945
File SHA-256fdbf6bd3d6b7b23bd6c866a89b6b01b8d6a4a74b835b11bd7b1311db564fc124
PDF Metadata Author.橡.murota
PDF Metadata Producer.橡.Microsoft Word Acrobat PDFWriter 4.0 Windows
FCC.gov SourcesFCC.gov 155852
