METROLRCK3X01 Touch Probe and Touch... - FCC ID AORMETROLRCK3X01
FCC ID AORMETROLRCK3X01
Setup Photo.pdf
Touch Probe and Touch Switch
Document preview loads when visible.
Document Details
| FCC ID | AORMETROLRCK3X01 |
|---|---|
| Document ID | 6665359 |
| Document Type | Test Setup Photos |
| Description | Setup Photo.pdf |
| Document Title | Setup Photo_(TERF2211002161ER-P)x |
| Applicant | Metrol Co., Ltd. |
| Equipment Class | Touch Probe and Touch Switch |
| Product Code | METROLRCK3X01 |
| Application ID | CcU7+ssbRWAJ48Gg7YGkzg== |
| Application Purpose | Original Equipment |
| Application Date | 2023-07-19 |
| Frequency Range | 2404-2476 MHz |
| FRN | 0021494224 |
| Test Firm | SGS Taiwan Ltd. Central RF Lab |
| Certified By | Jim Chang Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2023-07-16 |
| Available | 2023-07-19 |
| Created | 2023-06-02 |
| Modified | 2023-06-02 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 1763015 |
| File SHA-256 | dc89e4a10a503b905ae9ff6fc0aaae8f8fb991ee3003e43b235de4b24db06095 |
| PDF Metadata Author | Yami_Kuo |
| PDF Metadata Producer | Acrobat Distiller 20.0 (Windows) Yami_Kuo |
| FCC.gov Sources | FCC.gov 6665359 |
