AKGN5H BLUETOOTH HEADSET Test Setup Photos - FCC ID APIAKGN5H
FCC ID APIAKGN5H
Test setup photos for FCC
BLUETOOTH HEADSET
Document preview loads when visible.
Document Details
| FCC ID | APIAKGN5H |
|---|---|
| Document ID | 6946837 |
| Document Type | Test Setup Photos |
| Description | Test setup photos for FCC |
| Applicant | Harman International Industries, Inc |
| Equipment Class | BLUETOOTH HEADSET |
| Product Code | AKGN5H |
| Application ID | 2ViVFNXQ/FF0h5n5NKdEJg== |
| Application Purpose | Original Equipment |
| Application Date | 2023-11-28 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0024748147 |
| Test Firm | SGS-CSTC Standards Technical Services Co., Ltd. Sh |
| Certified By | Terry Shi |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 05/12/2024 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2023-11-28 |
| Available | 2024-05-12 |
| Created | 2023-11-23 |
| Modified | 2023-11-23 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 648598 |
| File SHA-256 | 59d558306c5eab96ae5012d42c19a35ae5cace1ac5c5bf020b93fcf25333d60e |
| PDF Metadata Producer | Microsoft® Word for Microsoft 365 Microsoft® Word for Microsoft 365 |
| FCC.gov Sources | FCC.gov 6946837, FCC.gov 6946711 |
