DMR0138 Household microwave oven Teardown... - FCC ID APYDMR0138

FCC ID APYDMR0138

Side View with Outer Enclosure Removed

Household microwave oven

by Sharp Corporation

Side View with Outer Enclosure Removed

Document Details

FCC IDAPYDMR0138
Document ID180778
Document TypeInternal Photos
DescriptionSide View with Outer Enclosure Removed
ApplicantSharp Corporation
Equipment ClassHousehold microwave oven
Product CodeDMR0138
Application IDNV61wCdOmv04T5ydQbF4yg==
Application PurposeOriginal Equipment
Application Date2001-12-07
Frequency Range2450 MHz
FRN0005810866
Test FirmSharp Corporation
Certified ByF. Kontani Manager, Reliability Control Center
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-11-26
Available2001-12-07
Created2001-11-01
Modified2001-11-01
Pages0
File TypeJPEG Image
File Size120768
File SHA-256f57161828e4e4e2e04b6eead5d631e4943ce0448e34c4e37aefa4192b542e439
FCC.gov SourcesFCC.gov 180778
