FCC ID APYHRO00239
Smart Phone
by Sharp Corporation
Grantee Code: APY Product Code: HRO00239
Latest application date: 2016-07-22
Device Images
FCC ID Device Details
| FCC ID | APYHRO00239 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | APY |
| Product Code | HRO00239 |
| Applicant Business | Sharp Corporation 🇯🇵 |
| Related Domains |  sharp.co.jp  sharpsec.com |
| Equipment Class | Smart Phone |
| Test Firm | Japan Qlty. Assur. Org. Kitakansai Testing Center |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-07-22 |
| 2402-2480 MHz | Original Equipment | 2016-07-22 |
| 1850.2-1909.8 MHz | Original Equipment | 2016-07-22 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 12_User Manual_APYHRO00239.pdf | Users Manual | 2017-01-19 | PDF 2.5 MB |
| Z1_DoC_Bluetooth_Compliance_APYHRO00239.pdf | Users Manual | 2017-01-19 | PDF 414.6 KB |
| 07-2_Photo_Internal_APYHRO00239.pdf | Internal Photos | 2017-01-19 | PDF 579.4 KB |
| 07-1_Photo_External_APYHRO00239.pdf | External Photos | 2017-01-19 | PDF 260.4 KB |
| 03-1_Declaration_FCC-ID_Visibility_APYHRO00239.pdf | ID Label/Location Info | 2016-07-22 | PDF 283.8 KB |
| 03-2_FCC ID steps_APYHRO00239.pdf | ID Label/Location Info | 2016-07-22 | PDF 274.5 KB |
| 08_FCC ID Location APYHRO00239.pdf | ID Label/Location Info | 2016-07-22 | PDF 181.9 KB |
| Z4_UL e-labeling _FCC_APYHRO00239.pdf | ID Label/Location Info | 2016-07-22 | PDF 87.7 KB |
| Pt15B_APYHRO00239_TestSetupPhoto(confidential)_11366681H-B.pdf | Test Setup Photos | 2017-01-19 | PDF 662.6 KB |
| Pt15C(BT)_APYHRO00239_TestSetupPhoto(confidential)_KL80160220.pdf | Test Setup Photos | 2017-01-19 | PDF 180.9 KB |
| Pt15C(WLAN_BT-LE)_APYHRO00239_TestSetupPhoto(confidential)_KL80160221.pdf | Test Setup Photos | 2017-01-19 | PDF 180.9 KB |
| Pt24E(PCS)_APYHRO00239_TestSetupPhoto(confidential)_KL80160219.pdf | Test Setup Photos | 2017-01-19 | PDF 93.5 KB |
| SAR_APYHRO00239_TestSetupPhoto(confidential)_KL80160218.pdf | Test Setup Photos | 2017-01-19 | PDF 171.5 KB |
| Pt15B_APYHRO00239_TestReport_11366681H-B.pdf | Test Report | 2016-07-22 | PDF 587.4 KB |
| Pt15C(BT)_APYHRO00239_TestReport_KL80160220.pdf | Test Report | 2016-07-22 | PDF 819.3 KB |
| Pt15C(WLAN_BT-LE)_APYHRO00239_TestReport_KL80160221.pdf | Test Report | 2016-07-22 | PDF 1.5 MB |
| Pt24E(PCS)_APYHRO00239_TestReport_KL80160219.pdf | Test Report | 2016-07-22 | PDF 445 KB |
| 02_ConfidentialRequest_APYHRO00239.pdf | Cover Letter(s) | 2016-07-22 | PDF 354.9 KB |
| Signature Authorization Letter_Oct21-2015.pdf | Cover Letter(s) | 2016-07-22 | PDF 454.7 KB |
| SAR_APYHRO00239_Appendix1_KL80160218.pdf | RF Exposure Info | 2016-07-22 | PDF 305.2 KB |
| SAR_APYHRO00239_Appendix2_KL80160218.pdf | RF Exposure Info | 2016-07-22 | PDF 346.1 KB |
| SAR_APYHRO00239_Appendix3_KL80160218.pdf | RF Exposure Info | 2016-07-22 | PDF 847.9 KB |
| SAR_APYHRO00239_Appendix4_KL80160218.pdf | RF Exposure Info | 2016-07-22 | PDF 822.8 KB |
| SAR_APYHRO00239_TestReport_KL80160218.pdf | RF Exposure Info | 2016-07-22 | PDF 440.5 KB |
| 06_BlockDiagram_APYHRO00239.pdf Metadata only | Block Diagram | PDF 148.9 KB | |
| 05-1_Schematic_Main-PWB_APYHRO00239.pdf Metadata only | Schematics | PDF 557.3 KB | |
| 05-2_Schematic_Prox-PWB_APYHRO00239.pdf Metadata only | Schematics | PDF 56.8 KB | |
| 05-3_Schematic_USB-PWB_APYHRO00239.pdf Metadata only | Schematics | PDF 58.9 KB | |
| 05-4_Schematic_Speaker-PWB_APYHRO00239.pdf Metadata only | Schematics | PDF 53.4 KB | |
| 05-5_Schematic_Shutter-PWB_APYHRO00239.pdf Metadata only | Schematics | PDF 50.4 KB | |
| 05-6_Schematic_Jack-FPC_APYHRO00239.pdf Metadata only | Schematics | PDF 54 KB | |
| 05-7_Schematic_Buzzer-FPC_APYHRO00239.pdf Metadata only | Schematics | PDF 48.8 KB | |
| 04_Model Description_APYHRO00239.pdf Metadata only | Operational Description | PDF 181.4 KB | |
| 10-1_Theory of Operation_GSM_APYHRO00239_rev1.pdf Metadata only | Operational Description | PDF 11.8 KB | |
| 10-2_Theory of Operation_WLAN_BT_APYHRO00239.pdf Metadata only | Operational Description | PDF 7.8 KB | |
| Z2 Antenna Drawing (Main Sub WLAN BT) APYHRO00239.pdf Metadata only | Operational Description | PDF 313.3 KB | |
| Z3_WLAN_Software configuration information for restriction_APYHRO00239.pdf Metadata only | SDR Software/Security Inf | PDF 788.3 KB | |
| Z5_AXGP_Software configuration information for restriction_APYHRO00239.pdf Metadata only | SDR Software/Security Inf | PDF 99.8 KB | |
| 09_Procedure_OutputPower_Alignment_2G_APYHRO00239.pdf Metadata only | Parts List/Tune Up Info | PDF 24.7 KB | |
| 11-1_Tune up procedure_GSM_APYHRO00239_rev1.pdf Metadata only | Parts List/Tune Up Info | PDF 15.7 KB | |
| 11-2_Tune up procedure_BT_APYHRO00239.pdf Metadata only | Parts List/Tune Up Info | PDF 29.4 KB | |
| 11-3_Tune up procedure_WLAN_APYHRO00239.pdf Metadata only | Parts List/Tune Up Info | PDF 35.1 KB | |
| 13_PartsList_APYHRO00239.pdf Metadata only | Parts List/Tune Up Info | PDF 47 KB |
Application Information
| Application ID | z6BaspomcvhYSGr5P2zyqw== |
|---|---|
| Final Action Date | 2016-07-22 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005810866 |
| Model | HRO00239 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Smart Phone |
| Responsible Party | Taihei Ohtsuka, Division Manager, Head of Quality promotion div., fcc-contact@sharp.co.jp , +81-50-5433-4157 |
| Technical Contact | Steve Petruska, Sharp Electronics Corporation, spetrusk@sharpsec.com , 201-529-9689 |
| Non-Technical Contact | Steve Petruska, Sharp Electronics Corporation, spetrusk@sharpsec.com , 201-529-9689 |
| Test Firm | Kousei Shibata, Japan Qlty. Assur. Org. Kitakansai Testing Center, shibata-kousei@jqa.jp  , 81-72-640-5270 |
| TCB Email | LST.FRE.CertNotice@ul.com  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 01/19/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. SAR compliance for body worn operating configurations must be restricted to belt-clips and holsters described in this filing, or which maintain a minimum separation distance of 1.0 cm and which contain no metallic component in the assembly. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (hotspot mode) and simultaneous transmission use conditions are 0.54 W/kg, 0.34 W/kg, 0.34 W/kg and 0.82 W/kg, respectively. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| z6BaspomcvhYSGr5P2zyqw== | 2016-07-22 | Original Equipment |
| uG02eb+vw7inSsmXbmtCMw== | 2016-07-22 | Original Equipment |
| scFjk7i80M+Y5U7lppcJ2A== | 2016-07-22 | Original Equipment |
| 8Yj18LRJ0jqCxrbjVs+mFA== | 2016-07-22 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application z6BaspomcvhYSGr5P2zyqw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/22/2016 Application Dated: 07/22/2016 |
| Sharp Corporation |
| 1 Takumi-cho, Sakai-ku, Sakai City |
| Osaka, 590-8522 Japan |
| Attention: Taihei Ohtsuka , Division Manager, Head of Quality promotion div. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | APYHRO00239 |
| Name of Grantee: | Sharp Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Smart Phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0032 | ||
| CC | 15C | 2412.0 - 2462.0 | 0.1452 |
| Output power listed is conducted. SAR compliance for body worn operating configurations must be restricted to belt-clips and holsters described in this filing, or which maintain a minimum separation distance of 1.0 cm and which contain no metallic component in the assembly. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (hotspot mode) and simultaneous transmission use conditions are 0.54 W/kg, 0.34 W/kg, 0.34 W/kg and 0.82 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application z6BaspomcvhYSGr5P2zyqw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sharp Corporation 1 Takumi-cho, Sakai-ku, Sakai City Osaka, 590-8522 Japan |
