FCC ID ARA-COMPACT2X
Base Station Transceiver
by Telrad Networks Ltd
Grantee Code: ARA Product Code: COMPACT2X
Latest application date: 2015-10-19
Device Images
FCC ID Device Details
| FCC ID | ARA-COMPACT2X |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | ARA |
| Product Code | COMPACT2X |
| Applicant Business | Telrad Networks Ltd 🇮🇱 |
| Related Domains |  telrad.com |
| Equipment Class | Base Station Transceiver |
| Test Firm | Israel Testing Laboratories |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2498.5-2687.5 MHz | Class II permissive change or modification of presently authorized equipment | 2015-10-19 |
| 2498.5-2687.5 MHz | Original Equipment | 2014-07-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-10-19 | PDF 1.2 MB |
| Users Manual | Users Manual | 2014-07-21 | PDF 2.4 MB |
| Internal Photos 1 | Internal Photos | 2014-07-21 | PDF 3.3 MB |
| Internal Photos 2 | Internal Photos | 2014-07-21 | PDF 3.4 MB |
| Internal Photos 3 | Internal Photos | 2014-07-21 | PDF 3.8 MB |
| Internal Photos 4 | Internal Photos | 2014-07-21 | PDF 2 MB |
| External Photos | External Photos | 2014-07-21 | PDF 2.7 MB |
| Label Location | ID Label/Location Info | 2014-07-21 | PDF 240.3 KB |
| Label Sample | ID Label/Location Info | 2014-07-21 | PDF 98.8 KB |
| Operational Description | Operational Description | 2014-07-21 | PDF 9.3 KB |
| Test Setup Photos | Test Setup Photos | 2015-10-19 | PDF 106.8 KB |
| Test Setup Photos | Test Setup Photos | 2014-07-21 | PDF 3.9 MB |
| Test Report | Test Report | 2015-10-19 | PDF 3.5 MB |
| Test Report | Test Report | 2014-07-21 | PDF 5.5 MB |
| 731 Form Signature Authorization Letter | Cover Letter(s) | 2015-10-19 | PDF 56.7 KB |
| Authorization Letter | Cover Letter(s) | 2015-10-19 | PDF 57.5 KB |
| Class II Permissive Change Letter | Cover Letter(s) | 2015-10-19 | PDF 93.4 KB |
| Authorization Letter | Cover Letter(s) | 2014-07-21 | PDF 60.9 KB |
| Confidentiality Letter | Cover Letter(s) | 2014-07-21 | PDF 118 KB |
| Form Authorization Letter | Cover Letter(s) | 2014-07-21 | PDF 58.9 KB |
| RF Exposure | RF Exposure Info | 2015-10-19 | PDF 23.7 KB |
| RF Exposure | RF Exposure Info | 2014-07-21 | PDF 28.1 KB |
| Tune Up Info | Parts List/Tune Up Info | 2014-07-21 | PDF 33.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 63.9 KB | |
| Schematics Metadata only | Schematics | PDF 3.1 MB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 608.6 KB |
Application Information
| Application ID | B2ZdJwRyRN/7kJCpk3XAMg== |
|---|---|
| Final Action Date | 2015-10-19 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0023140502 |
| Model | COMPACT2X |
| Frequency Range | 2498.5-2687.5 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | Base Station Transceiver |
| Responsible Party | Yishai Amsterdamer, VP R&D;, yishai.amsterdamer@telrad.com , 5182692344 |
| Test Firm | IIan Cohen, Israel Testing Laboratories, sraz@itl.co.il  , 972-3-5339022 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is the maximum conducted. The antenna(s) used for this transmitter must be fixed-mounted on permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3). (Date of Grant: 07/21/2014) Class II Permissive Change: This Class II Permissive Change is to add the 20 MHz bandwidth. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| B2ZdJwRyRN/7kJCpk3XAMg== | 2015-10-19 | Class II permissive change or modification of presently authorized equipment |
| Pi59cs12NpobaMynApnhUQ== | 2014-07-21 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application Pi59cs12NpobaMynApnhUQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/21/2014 Application Dated: 07/21/2014 |
| Telrad Networks Ltd |
| Industrial Center |
| PO Box 6118 |
| Lod, 711600 Israel |
| Attention: Yishai Amsterdamer , VP R&D |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ARA-COMPACT2X |
| Name of Grantee: | Telrad Networks Ltd |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Base Station Transceiver |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 27 | 2498.5 - 2687.5 | 29.992 | 200.0 Hz | 5M00W7D |
| MO | 27 | 2501.0 - 2685.0 | 29.717 | 400.0 Hz | 10M0W7D |
| Power output listed is the maximum conducted. The antenna(s) used for this transmitter must be fixed-mounted on permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3). |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application Pi59cs12NpobaMynApnhUQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Telrad Networks Ltd Industrial Center PO Box 6118 Lod, 711600 Israel |
Date of Grant: 07/21/2014 Application Dated: 07/21/2014 |
| Attention: Yishai Amsterdamer , VP R&D |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ARA-COMPACT2X |
| Name of Grantee: | Telrad Networks Ltd |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Base Station Transceiver |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 27 | 2498.5 - 2687.5 | 29.992 | 200.0 Hz | 5M00W7D |
| MO | 27 | 2501.0 - 2685.0 | 29.717 | 400.0 Hz | 10M0W7D |
| Power output listed is the maximum conducted. The antenna(s) used for this transmitter must be fixed-mounted on permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3). |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/19/2015 Application Dated: 10/19/2015 |
| Telrad Networks Ltd |
| Industrial Center |
| PO Box 6118 |
| Lod, 711600 Israel |
| Attention: Yishai Amsterdamer , VP R&D |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ARA-COMPACT2X |
| Name of Grantee: | Telrad Networks Ltd |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Base Station Transceiver |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 27 | 2498.5 - 2687.5 | 29.992 | 200.0 Hz | 5M00W7D |
| MO | 27 | 2501.0 - 2685.0 | 29.717 | 400.0 Hz | 10M0W7D |
| MO | 27 | 2506.0 - 2680.0 | 35.2 | 200.0 Hz | 20M0W7D |
| Power output listed is the maximum conducted. The antenna(s) used for this transmitter must be fixed-mounted on permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3). (Date of Grant: 07/21/2014) Class II Permissive Change: This Class II Permissive Change is to add the 20 MHz bandwidth. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application B2ZdJwRyRN/7kJCpk3XAMg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Telrad Networks Ltd Industrial Center PO Box 6118 Lod, 711600 Israel |
Date of Grant: 10/19/2015 Application Dated: 10/19/2015 |
| Attention: Yishai Amsterdamer , VP R&D |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ARA-COMPACT2X |
| Name of Grantee: | Telrad Networks Ltd |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Base Station Transceiver |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 27 | 2498.5 - 2687.5 | 29.992 | 200.0 Hz | 5M00W7D |
| MO | 27 | 2501.0 - 2685.0 | 29.717 | 400.0 Hz | 10M0W7D |
| MO | 27 | 2506.0 - 2680.0 | 35.2 | 200.0 Hz | 20M0W7D |
| Power output listed is the maximum conducted. The antenna(s) used for this transmitter must be fixed-mounted on permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3). (Date of Grant: 07/21/2014) Class II Permissive Change: This Class II Permissive Change is to add the 20 MHz bandwidth. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
