FCC ID ARG-OS-868
OS-868
by OSIM INTERNATIONAL LTD
Grantee Code: ARG Product Code: OS868
Latest application date: 2016-08-15
Device Images
FCC ID Device Details
| FCC ID | ARG-OS-868 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | ARG |
| Product Code | OS868 |
| Applicant Business | OSIM INTERNATIONAL LTD 🇸🇬 |
| Related Domains |  osim.com.sg |
| Equipment Class | OS-868 |
| Test Firm | Intertek Testing Services Limited Shanghai |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-08-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-08-15 | PDF 191.9 KB |
| Internal picture | Internal Photos | 2016-08-15 | PDF 109.2 KB |
| External picture rev1 | External Photos | 2016-08-15 | PDF 803.1 KB |
| Label | ID Label/Location Info | 2016-08-15 | PDF 4 MB |
| test Setup rev1 | Test Setup Photos | 2016-08-15 | PDF 218 KB |
| report rev1 | Test Report | 2016-08-15 | PDF 1 MB |
| Confidentiality | Cover Letter(s) | 2016-08-15 | PDF 185.9 KB |
| FCC agency | Cover Letter(s) | 2016-08-15 | PDF 40.8 KB |
| Modular Approval_FCC rev1 | Cover Letter(s) | 2016-08-15 | PDF 84.5 KB |
| report_FCC MPE | RF Exposure Info | 2016-08-15 | PDF 64.1 KB |
| Confidential_Block_chip Metadata only | Block Diagram | PDF 138.5 KB | |
| Confidential_Block_module Metadata only | Block Diagram | PDF 61.3 KB | |
| Confidential_Schematic Metadata only | Schematics | PDF 39.5 KB | |
| Confidential_Operation description Metadata only | Operational Description | PDF 425.1 KB |
Application Information
| Application ID | VYd8Xh+jXqQGw/VEN1qQrQ== |
|---|---|
| Final Action Date | 2016-08-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0021422845 |
| Model | OS-868 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | OS-868 |
| Responsible Party | Christina Cheong, Manager, Purchasing and Supply, christina.cheong@osim.com.sg , (65) 6747 6866 |
| Agent | wakeyou wakeyou wakeyou, Intertek Testing Services Limited Shanghai, wakeyou.wang@intertek.com  , 86-21-61278448 |
| Technical Contact | Wakeyou Wang, Intertek Testing Services Limited Shanghai, wakeyou.wang@intertek.com , 86-21-61278448 |
| Test Firm | Jonny Jing, Intertek Testing Services Limited Shanghai, jonny.jing@intertek.com , 86-21-61278271 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is Conducted. Limited Modular Approval. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| VYd8Xh+jXqQGw/VEN1qQrQ== | 2016-08-15 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0022000 | 15C |
Grants
TCB Grant - Application VYd8Xh+jXqQGw/VEN1qQrQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 08/15/2016 Application Dated: 08/12/2016 |
| OSIM INTERNATIONAL LTD |
| 65 Ubi Avenue 1 |
| OSIM Headquarters |
| Singapore, 408939 Singapore |
| Attention: Christina Cheong , Manager, Purchasing and Supply |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ARG-OS-868 |
| Name of Grantee: | OSIM INTERNATIONAL LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | OS-868 |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 |
| Power Output listed is Conducted. Limited Modular Approval. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application VYd8Xh+jXqQGw/VEN1qQrQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
OSIM INTERNATIONAL LTD 65 Ubi Avenue 1 OSIM Headquarters Singapore, 408939 Singapore |
Date of Grant: 08/15/2016 Application Dated: 08/12/2016 |
| Attention: Christina Cheong , Manager, Purchasing and Supply |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ARG-OS-868 |
| Name of Grantee: | OSIM INTERNATIONAL LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | OS-868 |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 |
| Power Output listed is Conducted. Limited Modular Approval. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
