Nokia of America Corporation PCS RRH 4x45W BBTRX-05

An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product. For example, the grantee code for FCC ID: AS5BBTRX-05 is AS5. The remaining characters of the FCC ID, BBTRX-05, are often associated with the product model, but they can be random. These letters are chosen by the applicant. In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.

Purchase on Amazon: PCS RRH 4x45W

FCC ID AS5BBTRX-05 Test-Setup-Photos
FCC ID AS5BBTRX-05 Test-Setup-Photos
FCC ID AS5BBTRX-05 Test-Setup-Photos
FCC ID AS5BBTRX-05 Test-Setup-Photos
FCC ID AS5BBTRX-05 Test-Setup-Photos

*Please Check Individual Documents for more images

App # Purpose Date Unique ID
1 Original Equipment 2012-04-30 QLaFSIEoIY6ZyQruFAm3pQ==
2 Class II Permissive Change 2015-07-09 ofqwbB7QuVcf8fhR+wLWVw==
3 Class II Permissive Change 2016-10-06 C830h5dDMjUPNhPwIo4v0A==
4 Class II Permissive Change 2018-11-07 8LxjxH8lPY3NGlzxjqo3nQ==

Operating Frequencies

Device operates within approved frequencies overlapping with the following cellular bands: LTE 25,1900+ DOWN | LTE 65,2100+ UP | UMTS CH 25 DOWN |
Frequency RangePower OutputToleranceEmission DesignatorRule PartsGrant Notes App #
1.93-1.995 GHz40 Watts0.05ppm10M0F9W24EMO 2.1
1.93-1.995 GHz25 Watts0.05ppm1M25F9W24EMO 2.2
1.93-1.995 GHz20 Watts0.05ppm5M00F9W24EMO 2.3
1.93-1.995 GHz25 Watts0.05ppm1M25F9W24E 1.1
1.93-1.995 GHz20 Watts0.05ppm5M00F9W24E 1.2
1.93-1.995 GHz40 Watts0.05ppm10M0F9W24EMO 3.1
1.93-1.995 GHz25 Watts0.05ppm1M25F9W24EMO 3.2
1.93-1.995 GHz20 Watts0.05ppm5M00F9W24EMO 3.3
1.93-1.995 GHz40 Watts0.05ppm10M0F9W24EMO 4.1
1.93-1.995 GHz25 Watts0.05ppm1M25F9W24EMO 4.2
1.93-1.995 GHz20 Watts0.05ppm5M00F9W24EMO 4.3
1.93-1.995 GHz40 Watts0.05ppm14M0F9W24EMO 4.4
