GEMRM10U X-Band Radar Transceiver Schematics - FCC ID ASLGEMRM-10U
FCC ID ASLGEMRM-10U
Schematics
X-Band Radar Transceiver
Document preview loads when visible.
Document Details
| FCC ID | ASLGEMRM-10U |
|---|---|
| Document ID | 557865 |
| Document Type | Schematics |
| Description | Schematics |
| Document Title | Dokument: |
| Applicant | Raytheon Anschuetz GmbH High Seas Products |
| Equipment Class | X-Band Radar Transceiver |
| Product Code | GEMRM10U |
| Application ID | GkmsutHYpPwFvrpBw/uKyg== |
| Application Purpose | Original Equipment |
| Application Date | 2005-07-01 |
| Frequency Range | 9410 MHz |
| FRN | 0009629890 |
| Test Firm | EMCCons Dr. Rasek GmbH & Co.KG |
| Certified By | Robert Zissen Dipl.-Ing. |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2005-07-01 |
| Available | 2005-07-01 |
| Created | 2005-06-08 |
| Modified | 2005-06-08 |
| Pages | 10 |
| File Type | Adobe Acrobat PDF |
| File Size | 1147169 |
| File SHA-256 | a90ba5b3a42eaffadf18b54a72737ecbdbfd691821c56bab63ca478e8d87ae28 |
| PDF Metadata Author | tdmay |
| PDF Metadata Producer | BroadVision, Inc. Acrobat Distiller 6.0 (Windows) |
| FCC.gov Sources | FCC.gov 557865 |
