92U05A28780 Bluetooth Socket Modem Block... - FCC ID AU792U05A28780

FCC ID AU792U05A28780

Block Diagram 2

Bluetooth Socket Modem

by Multi Tech Systems Inc

Document preview loads when visible.

Document Details

FCC IDAU792U05A28780
Document ID550919
Document TypeBlock Diagram
DescriptionBlock Diagram 2
Document TitleF:\CAD\PPC\234a0_a.PDF
ApplicantMulti Tech Systems Inc
Equipment ClassBluetooth Socket Modem
Product Code92U05A28780
Application IDvX+1/ua9FPANeX80KUWo7Q==
Application PurposeOriginal Equipment
Application Date2005-06-14
Frequency Range2402-2480 MHz
FRN0009336579
Test FirmRFI Global Services Ltd.
Certified ByM. Sundeen Quality Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2005-06-14
Available2005-06-14
Created2005-06-07
Modified2005-06-07
Pages1
File TypeAdobe Acrobat PDF
File Size20664
File SHA-256ad8a7875ef180e3408b918b86809089d2d15bcedea2ef4868a0301d93a387ce4
PDF Metadata AuthorPPC
PDF Metadata ProducerF:\CAD\PPC\234a0_a.vcd Acrobat PDFWriter 4.05 for Windows
