FCC ID AXG-RF2TPA
Telemetry Remote Control System
by Konishi Mokei Co., Ltd.
Grantee Code: AXG Product Code: RF2TPA
Latest application date: 2016-04-14
Device Images
FCC ID Device Details
| FCC ID | AXG-RF2TPA |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | AXG |
| Product Code | RF2TPA |
| Applicant Business | Konishi Mokei Co., Ltd. 🇯🇵 |
| Equipment Class | Telemetry Remote Control System |
| Test Firm | PCTEST Engineering Laboratory, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2404-2479 MHz | Original Equipment | 2016-04-14 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-10-11 | PDF 186.3 KB |
| Internal Photographs | Internal Photos | 2016-10-11 | PDF 264.2 KB |
| External Photographs | External Photos | 2016-10-11 | PDF 203.3 KB |
| FCC ID Label and Location | ID Label/Location Info | 2016-04-14 | PDF 220.4 KB |
| Test Setup Photographs | Test Setup Photos | 2016-10-11 | PDF 804.6 KB |
| Test Report | Test Report | 2016-04-14 | PDF 1.8 MB |
| Attestation Letter | Attestation Statements | 2016-04-14 | PDF 73.2 KB |
| Modular Approval Request Letter | Attestation Statements | 2016-04-14 | PDF 247.7 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-04-14 | PDF 101.4 KB |
| RF Exposure Info | RF Exposure Info | 2016-04-14 | PDF 124.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 620.5 KB | |
| Schematics Metadata only | Schematics | PDF 730.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 624.8 KB |
Application Information
| Application ID | JsfBJMEBDuNH5fNBWuMneA== |
|---|---|
| Final Action Date | 2016-04-14 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0027839810 |
| Model | RF2TPA |
| Frequency Range | 2404-2479 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Telemetry Remote Control System |
| Responsible Party | Munekazu Takamura, rcdepot.takamura7@gmail.com  , +81-4-7197-2958 |
| Technical Contact | Randy Ortanez, PCTEST Engineering Laboratory, Inc., tcb@pctestlab.com  , 410-290-6652 |
| Test Firm | Randy Ortanez, PCTEST Engineering Laboratory, Inc., lab@pctestlab.com , 410-290-6652 |
| TCB Email | tcb@pctestlab.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 10/11/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited modular approval. Power output listed is peak conducted. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed in the host device to provide a separation distance of at least 5 cm from all persons and must operate with a maximum duty factor of 19%. The antenna for this device must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| JsfBJMEBDuNH5fNBWuMneA== | 2016-04-14 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2404-2479 MHz | 0.1240000 | 15C |
Grants
TCB Grant - Application JsfBJMEBDuNH5fNBWuMneA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PCTEST Engineering Laboratory, LLC 7185 Oakland Mills Road Columbia, MD 21046 |
Date of Grant: 04/14/2016 Application Dated: 04/14/2016 |
| Konishi Mokei Co., Ltd. |
| 584-6 Oodonoi, |
| Noda-shi |
| Chiba-ken, 278-0017 Japan |
| Attention: Munekazu Takamura |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AXG-RF2TPA |
| Name of Grantee: | Konishi Mokei Co., Ltd. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Telemetry Remote Control System |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2404.0 - 2479.0 | 0.124 |
| Limited modular approval. Power output listed is peak conducted. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed in the host device to provide a separation distance of at least 5 cm from all persons and must operate with a maximum duty factor of 19%. The antenna for this device must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
EAS Grant - Application JsfBJMEBDuNH5fNBWuMneA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Konishi Mokei Co., Ltd. 584-6 Oodonoi, Noda-shi Chiba-ken, 278-0017 Japan |
Date of Grant: 04/14/2016 Application Dated: 04/14/2016 |
| Attention: Munekazu Takamura |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | AXG-RF2TPA |
| Name of Grantee: | Konishi Mokei Co., Ltd. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Telemetry Remote Control System |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2404.0 - 2479.0 | 0.124 |
| Limited modular approval. Power output listed is peak conducted. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed in the host device to provide a separation distance of at least 5 cm from all persons and must operate with a maximum duty factor of 19%. The antenna for this device must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
