89FT7166 WAVE PTX TWO-WAY RADIO User Manual - FCC ID AZ489FT7166
FCC ID AZ489FT7166
User Guide
WAVE PTX TWO-WAY RADIO
Document preview loads when visible.
Document Details
| FCC ID | AZ489FT7166 |
|---|---|
| Document ID | 6354265 |
| Document Type | Users Manual |
| Description | User Guide |
| Document Title | WAVE TWO-WAY RADIO TLK 110 User Guide |
| Applicant | Motorola Solutions, Inc. |
| Equipment Class | WAVE PTX TWO-WAY RADIO |
| Product Code | 89FT7166 |
| Application ID | jBhn4KCrcucIjI+kIbEhhA== |
| Application Purpose | Original Equipment |
| Application Date | 2023-02-06 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0003778479 |
| Test Firm | Sporton International Inc. (Kunshan) |
| Certified By | Jim Tsai Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 02/22/2023 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2023-02-03 |
| Available | 2023-02-22 |
| Created | 2022-10-14 |
| Modified | 2022-11-16 |
| Pages | 64 |
| File Type | Adobe Acrobat PDF |
| File Size | 608741 |
| File SHA-256 | 1891133650af03c8edd1f788e63dcedd36051ca71dab54a941230cbc61bdf27b |
| PDF Metadata Author | Motorola Solutions |
| PDF Metadata Producer | Motorola Solutions Antenna House PDF Output Library 7.1.1639 |
| FCC.gov Sources | FCC.gov 6354265, FCC.gov 6354232, FCC.gov 6354198, FCC.gov 6354158 |
