Document Details
| FCC ID | B32OMNI3600G |
|---|---|
| Document ID | 348881 |
| Document Type | RF Exposure Info |
| Description | SAR test report |
| Document Title | R0305223S.PDF |
| Applicant | VeriFone Inc |
| Equipment Class | Point of Sale Terminal |
| Product Code | OMNI3600G |
| Application ID | O9aPYCwparPBkFQatosvfg== |
| Application Purpose | Original Equipment |
| Application Date | 2003-08-15 |
| Frequency Range | 1850.2-1908.8 MHz |
| FRN | 0022825988 |
| Test Firm | Bay Area Compliance Laboratory |
| Certified By | William B. Morse Senior EMC Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-08-15 |
| Available | 2003-08-15 |
| Created | 2003-07-28 |
| Modified | 2003-08-05 |
| Pages | 59 |
| File Type | Adobe Acrobat PDF |
| File Size | 4111712 |
| File SHA-256 | d24ca035d119170507e58bcaa34c8a76d48e4c5c563cbf198405f7c14ce91778 |
| PDF Metadata Author | jennifer |
| PDF Metadata Producer | Acrobat PDFWriter 4.05 for Windows jennifer |
| FCC.gov Sources | FCC.gov 348881 |
