FCC ID B4OEC86XFPX
Wi-Fi + Bluetooth LE (WiBlue) module
by GT-tronics HK Ltd
Grantee Code: B4O Product Code: EC86XFPX
Latest application date: 2016-10-27
Device Images
FCC ID Device Details
| FCC ID | B4OEC86XFPX |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | B4O |
| Product Code | EC86XFPX |
| Applicant Business | GT-tronics HK Ltd |
| Related Domains |  gt-tronics.com |
| Equipment Class | Wi-Fi + Bluetooth LE (WiBlue) module |
| Test Firm | Dongguan Precise Testing Service Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-10-27 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_EC864FPA UserMan,r7 | Users Manual | 2016-10-27 | PDF 725.8 KB |
| 09_EC864FPA IntPho,r1 | Internal Photos | 2016-10-27 | PDF 365.2 KB |
| 08_EC864FPA ExtPho | External Photos | 2016-10-27 | PDF 755.2 KB |
| 06-07_EC864FPA LabelSmpl-Loc | ID Label/Location Info | 2016-10-27 | PDF 62.5 KB |
| 17_EC864FPA AntSpec,r3 | Operational Description | 2016-10-27 | PDF 69.4 KB |
| 10_EC864FPA TSup | Test Setup Photos | 2016-10-27 | PDF 188.7 KB |
| 14_EC864FPA TestRpt DTS-BLE, r5 | Test Report | 2016-10-27 | PDF 1.5 MB |
| 14_EC864FPA TestRpt DTS-WIFI, r5 | Test Report | 2016-10-27 | PDF 1.3 MB |
| 18_EC864FPA RFExp,r1 | RF Exposure Info | 2016-10-27 | PDF 21.1 KB |
| 12_EC864FPA BlkDia Metadata only | Block Diagram | PDF 91 KB | |
| 13_EC864FPA Schem,r1 Metadata only | Schematics | PDF 32.5 KB | |
| 11_EC864FPA OpDes,r2 Metadata only | Operational Description | PDF 118.1 KB | |
| 16_EC864FPA PartsLst Metadata only | Parts List/Tune Up Info | PDF 48.6 KB |
Application Information
| Application ID | 0+vcmLPmQQjKyHBDQk0Fow== |
|---|---|
| Final Action Date | 2016-10-27 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0021630322 |
| Model | EC86XFPX |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wi-Fi + Bluetooth LE (WiBlue) module |
| Responsible Party | Dennis Wong, Admin Asst, dwong@gt-tronics.com , +852-8100-1820 |
| Test Firm | Chris Du, Dongguan Precise Testing Service Co., Ltd., chris.du@pts-testing.com  , 86-769-8928-2919 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted.Singular Modular Approval. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. SAR evaluation is valid for mobile applications only (minimum distance of 20cm to human bodies). |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 0+vcmLPmQQjKyHBDQk0Fow== | 2016-10-27 | Original Equipment |
Grants
TCB Grant - Application 0+vcmLPmQQjKyHBDQk0Fow==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 10/27/2016 Application Dated: 10/27/2016 |
| GT-tronics HK Ltd |
| Unit 10, 2/F., Block B, Tonic Industrial |
| Center 19 Lam Hing Street, Kowloon Bay, |
| Kowloon, Hong Kong |
| Attention: Dennis Wong , Admin Asst |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | B4OEC86XFPX |
| Name of Grantee: | GT-tronics HK Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Wi-Fi + Bluetooth LE (WiBlue) module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 | |||
| 15C | 2412.0 - 2462.0 | 0.0581 |
| Power listed is conducted.Singular Modular Approval. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. SAR evaluation is valid for mobile applications only (minimum distance of 20cm to human bodies). |
EAS Grant - Application 0+vcmLPmQQjKyHBDQk0Fow==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
GT-tronics HK Ltd Unit 10, 2/F., Block B, Tonic Industrial Center 19 Lam Hing Street, Kowloon Bay, Kowloon, Hong Kong |
Date of Grant: 10/27/2016 Application Dated: 10/27/2016 |
| Attention: Dennis Wong , Admin Asst |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | B4OEC86XFPX |
| Name of Grantee: | GT-tronics HK Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Wi-Fi + Bluetooth LE (WiBlue) module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 | |||
| 15C | 2412.0 - 2462.0 | 0.0581 |
| Power listed is conducted.Singular Modular Approval. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. SAR evaluation is valid for mobile applications only (minimum distance of 20cm to human bodies). |
